TTETTLJANF-40.000000

Oscillators Overview

The TTETTLJANF-40.000000 is a temperature-compensated crystal oscillator (TCXO) manufactured by Taitien, operating at a nominal frequency of 40 MHz. It utilizes CMOS output logic and functions with a supply voltage of 3.3V. The component is housed in a compact 4-SMD, No Lead Exposed Pad package, designed for surface-mount assembly. This oscillator belongs to the Stratum 3 series, indicating specific performance standards for frequency stability and phase noise suitable for precision timing applications requiring thermal compensation.

Oscillators Feature Summary

• Integrated temperature compensation circuitry ensures stable frequency output across varying environmental conditions.
• CMOS output interface provides digital clock signals compatible with standard logic families.
• RoHS3 compliant construction supports environmentally regulated manufacturing requirements.

Oscillators Applications

• Precision timing circuits in telecommunications infrastructure
• Clock generation for high-speed data processing systems
• Navigation and positioning modules requiring stable reference frequencies

Oscillators Procurement Notes

Verify the exact ordering suffix against the manufacturer's current datasheet to confirm voltage levels and output types. Ensure the selected variant matches the required supply voltage and packaging specifications for your design. Cross-reference the RoHS compliance status with regional regulatory requirements before finalizing procurement orders.

Oscillators Selection Notes

Select this component when a stable 40 MHz reference is required in space-constrained designs. The exposed pad package facilitates thermal management and mechanical stability. Confirm that the CMOS output swing aligns with the input requirements of the downstream circuitry to ensure signal integrity without additional buffering.

Oscillators Part Context

This oscillator is part of Taitien's broader portfolio of controlled oscillators, specifically within the TCXO category. It complements other models like the TYEACDSANF series by offering enhanced frequency stability through active temperature compensation rather than passive clipping sine outputs.

Oscillators Replacement Considerations

Direct substitutes may include other 40 MHz TCXOs in similar SMD packages from Taitien or competitors. Verify pinout compatibility and electrical parameters such as supply voltage and load capacitance before substitution.
