TX-T30-05KP-27.000M

Oscillators Overview

The TX-T30-05KP-27.000M is a Temperature Compensated Crystal Oscillator (TCXO) manufactured by Transko Electronics, Inc. It operates at a nominal frequency of 27 MHz and delivers a clipped sine wave output signal. The device functions with a supply voltage of 3.3V and features high frequency stability rated at ±500ppb. It is housed in a compact 4-SMD, No Lead package with dimensions of 5.00mm x 3.20mm, suitable for surface-mount assembly.

Oscillators Feature Summary

• Provides precise timing signals via clipped sine wave output
• Ensures high frequency stability through temperature compensation
• Designed for low-power operation with 3.3V supply requirement

Oscillators Applications

• Phase-locked loop (PLL) circuits
• GPS/GNSS timing applications
• Frequency synthesizers

Oscillators Procurement Notes

Verify the specific ordering suffix to confirm the exact frequency tolerance and operating temperature range required for your design. Ensure that the 3.3V supply voltage aligns with your system power architecture. Confirm RoHS compliance status if environmental regulations apply to your manufacturing process. Cross-reference the pinout configuration with your PCB layout to ensure correct signal routing and ground connections.

Oscillators Selection Notes

Select this component when tight frequency stability is critical for synchronization tasks. The clipped sine wave output is suitable for driving digital logic or PLL inputs directly. Consider the small SMD footprint for space-constrained designs. Evaluate the ±500ppb stability against your system's jitter requirements. Ensure the operating temperature range covers your intended application environment.

Oscillators Part Context

This oscillator belongs to the TX-T series from Transko Electronics, which specializes in frequency control products for telecommunications and electronic systems. The series includes various TCXO models designed for different frequency and stability needs. This specific model targets applications requiring stable reference clocks in compact form factors, supporting modern portable and industrial electronics.

Oscillators Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Verify compatibility with existing circuit designs before considering alternative sources. Check for equivalent stability metrics and package dimensions if sourcing from other manufacturers.
