TX-T30-25JP-24.576M

Oscillators Overview

The TX-T30-25JP-24.576M is a Temperature Compensated Crystal Oscillator (TCXO) manufactured by Transko Electronics, Inc. It operates at a nominal frequency of 24.576 MHz and delivers a clipped sine wave output signal. The device is powered by a single 3.3V supply voltage and features a 4-SMD, No Lead surface-mount package with dimensions of 5.00mm x 3.20mm. It is designed for stable frequency generation in compact electronic systems requiring precise timing references.

Oscillators Feature Summary

• Provides temperature-compensated frequency stability using internal crystal technology
• Delivers a clipped sine wave output suitable for RF and communication interfaces
• Supports low-voltage operation with a 3.3V power supply requirement
• Utilizes a compact surface-mount package for automated PCB assembly

Oscillators Applications

• Telecommunications equipment requiring precise clock signals
• Frequency synthesizer circuits for signal generation
• Wireless communication modules needing stable oscillators
• Consumer electronics with tight timing constraints

Oscillators Procurement Notes

Verify the specific ordering suffix to ensure the correct output waveform and tolerance match the design requirements. Confirm that the 3.3V supply voltage aligns with the target system's power rails. Check the package outline drawing to ensure compatibility with the footprint on the printed circuit board. Ensure environmental conditions fall within the specified operating range for reliable performance.

Oscillators Selection Notes

Select this component when a clipped sine wave output is required rather than digital logic levels. Consider the thermal management capabilities of the enclosure as TCXOs generate heat during operation. Evaluate the need for temperature compensation versus standard XO types based on the application's stability requirements. Ensure the 4-SMD package size fits within the available space constraints of the final product design.

Oscillators Part Context

This oscillator belongs to the TX-T30 series from Transko Electronics, which specializes in frequency control products. The series is widely used in telecommunications and consumer electronics. The model number indicates a 24.576 MHz frequency and a 3.3V supply. It is part of a broader lineup offering various frequencies and output types for different industrial applications.

Oscillators Replacement Considerations

Direct substitutes include other Transko TCXOs with identical pinouts and electrical characteristics. Cross-reference with similar models from other manufacturers ensuring matching frequency, voltage, and package dimensions. Verify that alternative components support the same clipped sine wave output format to maintain interface compatibility.
