TYJTPLSANF-40.000000

Oscillators Overview

The Taitien TYJTPLSANF-40.000000 is a temperature-compensated crystal oscillator (TCXO) operating at a fundamental frequency of 40 MHz. It delivers a clipped sine wave output signal and functions within a supply voltage range of 2.5V. The component utilizes a basic crystal resonator and is housed in a compact 4-SMD, no-lead surface-mount package with dimensions of 2.50mm x 2.00mm x 0.80mm maximum height. Designed for reliability, it supports RoHS3 compliance and operates under Moisture Sensitivity Level 1 conditions.

Oscillators Feature Summary

• Temperature compensation ensures stable frequency performance across varying thermal environments
• Compact surface-mount footprint facilitates automated assembly and space-constrained designs
• Clipped sine wave output provides compatible signaling for digital clock inputs

Oscillators Applications

• Precision timing references for communication modules
• Clock generation for embedded microprocessors
• Synchronization circuits in portable electronic devices

Oscillators Procurement Notes

Verify the specific ordering suffix to confirm voltage requirements and stability specifications, as variations exist within the TY series. Confirm that the 2.5V supply requirement aligns with the target system design. Ensure compatibility with standard reflow soldering profiles for 4-SMD packages. Check for updated environmental compliance documentation if required by regional regulations.

Oscillators Selection Notes

Select this component when a low-voltage 2.5V TCXO is required for 40 MHz applications. Compare against similar models like TYETCCSANF-40.000000 which may offer different voltage ranges or stability metrics. Evaluate the trade-off between the clipped sine wave output and other waveform types based on downstream circuit sensitivity. Consider the physical size constraints relative to available PCB real estate.

Oscillators Part Context

This oscillator belongs to the Taitien TY series, a family of surface-mount temperature-compensated crystal oscillators. The series offers various frequency options and package sizes tailored for consumer electronics and industrial applications. The TYJTPLSANF variant specifically targets lower voltage operation compared to other series members.

Oscillators Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation.
