ULS2801H-883

$17.64

Description：TRANS 8NPN DARL 50V 18CERDIP
Series：-

SKU:6a7d013bf194 Category: Bipolar Transistor Arrays Brand: Allegro MicroSystems

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：TRANS 8NPN DARL 50V 18CERDIP
Series：-
Mfr：Allegro MicroSystems
Package：Bulk
Transistor Type：8 NPN Darlington
Current - Collector (Ic) (Max)：600mA
Voltage - Collector Emitter Breakdown (Max)：50V
Vce Saturation (Max) @ Ib, Ic：1.6V @ 500µA, 350mA
Current - Collector Cutoff (Max)：100µA
DC Current Gain (hFE) (Min) @ Ic, Vce：1000 @ 350mA, 2V
Power - Max：1W
Frequency - Transition：-
Operating Temperature：-55°C ~ 125°C (TA)
Mounting Type：Through Hole
Package / Case：18-CDIP (0.300", 7.62mm)
Supplier Device Package：18-CERDIP
Grade：-
Qualification：-

Download product information

ULS2801H-883

Overview

The ULS2801H-883 is a high-voltage, high-current Darlington transistor array manufactured by Allegro MicroSystems. It integrates eight independent NPN silicon power transistors arranged in eight banks. Each channel features built-in diodes and resistors to facilitate switching applications. The device is housed in a hermetically sealed ceramic LCC-20 package designed for military or aerospace environments requiring robust protection against moisture and contaminants.

Feature Summary

Integrates eight independent NPN Darlington transistor channels within a single component
Features built-in diodes and resistors integrated into each bank for circuit simplification
Constructed with hermetically sealed ceramic packaging for environmental durability

Applications

High voltage switching circuits
High current load driving applications
Military and aerospace electronic systems

Part Context

This component belongs to the ULx2801/ULx2804/ULx2823/ULx2824 family of high voltage high current Darlington arrays produced by Allegro. These devices are specifically engineered for demanding switching tasks where multiple isolated outputs are required from a compact footprint.

Replacement Considerations

Official documentation states these parts are discontinued and should not be purchased for new design applications. Recommended substitutions require contacting local Allegro field applications engineers or sales representatives for specific alternatives.
