V73305100-24.576-R

Oscillators Overview

The V73305100-24.576-R is a Voltage Controlled Crystal Oscillator (VCXO) manufactured by Aker Technology Corp, operating at a nominal frequency of 24.576 MHz. It utilizes HCMOS output logic and requires a supply voltage of 3.3V. The device features an enable/disable function for power management. It is housed in a 6-SMD, No Lead surface-mount package. Key electrical specifications include an Absolute Pull Range (APR) of ±100ppm and a frequency stability of ±50ppm. The component supports an operating temperature range of 0°C to 70°C.

Oscillators Feature Summary

• Voltage controlled crystal oscillator architecture with HCMOS output
• Integrated enable and disable control functionality
• Surface mount packaging designed for automated assembly

Oscillators Applications

• Clock signal generation in digital communication systems
• Frequency synthesis circuits requiring voltage tuning
• Embedded timing references for consumer electronics

Oscillators Procurement Notes

Verify the specific APR and temperature range against the official datasheet, as distributor listings may vary between ±100ppm/0-70°C and other variants. Confirm the 6-SMD package dimensions match the PCB footprint requirements. Ensure the 3.3V supply voltage aligns with the target circuit design before procurement.

Oscillators Selection Notes

Select this component when a precise 24.576 MHz reference with voltage control capabilities is required. The HCMOS output ensures compatibility with standard digital logic levels. Consider the ±50ppm stability for applications demanding moderate frequency accuracy within the specified commercial temperature range.

Oscillators Part Context

This part belongs to the V7330 series of VCXOs from Aker Technology Corp. These oscillators are designed to provide stable clock signals that can be adjusted via a control voltage. The series typically offers various frequencies and packages to suit different embedded system timing needs.

Oscillators Replacement Considerations

The V73305100-25.000-R is a documented substitute within the same product family, offering similar functionality at a 25.000 MHz frequency. Verify pinout and electrical parameters before substitution.
