VS-VSKD236/08PBF is listed in the Diode Arrays range at ChipApex. The manufacturer field lists Vishay General Semiconductor - Diodes Division. Its product description is DIODE MOD GP 800V 115A MAGNAPAK. Review the specifications below when checking this part for your BOM.
Diode Arrays specifications for VS-VSKD236/08PBF
- Description：DIODE MOD GP 800V 115A MAGNAPAK
- Series：-
- Mfr：Vishay General Semiconductor - Diodes Division
- Package：Bulk
- Diode Configuration：1 Pair Common Cathode
- Technology：Standard
- Voltage - DC Reverse (Vr) (Max)：800 V
- Current - Average Rectified (Io) (per Diode)：115A
- Voltage - Forward (Vf) (Max) @ If：-
- Speed：Standard Recovery >500ns, > 200mA (Io)
- Reverse Recovery Time (trr)：-
- Current - Reverse Leakage @ Vr：20 mA @ 800 V
- Operating Temperature - Junction：-40°C ~ 150°C
- Mounting Type：Chassis Mount
- Package / Case：3-MAGN-A-PAK™
- Supplier Device Package：MAGN-A-PAK®
- Grade：-
- Qualification：-
Diode Arrays datasheet and documents for VS-VSKD236/08PBF
Diode Arrays Overview
The VS-VSKD236/08PBF is a silicon controlled rectifier (SCR) module manufactured by Vishay General Semiconductor - Diodes Division. It features an INT-A-PAK package with screw mount installation. The device has a rated repetitive off-state voltage of 800 V and an RMS on-state current of 360 A. Non-repetitive peak on-state current is 5.5 kA, while the gate trigger current maximum is 5.765 kA. The forward voltage drop is 1.46 V at rated conditions. Operating junction temperature ranges from -40°C to +150°C.
Diode Arrays Feature Summary
- High power handling capability with 360 A RMS on-state current rating
- Robust surge withstand capacity with 5.5 kA non-repetitive peak current
- Integrated thermal management via INT-A-PAK baseplate design
- Wide operating temperature range suitable for industrial environments
Diode Arrays Applications
- Industrial motor drives and variable frequency drives
- High-power DC power supplies and rectifiers
- Resistive load control systems
- Welding equipment power stages
Diode Arrays Procurement Notes
Verify the specific voltage suffix in the part number against project requirements. Confirm mounting torque specifications using official Vishay mechanical drawings. Check RoHS compliance status through the manufacturer's latest documentation. Ensure heatsink compatibility with the INT-A-PAK footprint dimensions before integration.
Diode Arrays Selection Notes
Select this component when high current switching with moderate voltage blocking is required. Compare alternative SCR modules based on forward voltage characteristics and thermal resistance values. Evaluate package compatibility with existing PCB or chassis layouts. Consider derating factors for ambient temperature conditions exceeding standard ratings.
Diode Arrays Part Context
This device belongs to Vishay's VSKD series of high-power thyristor modules. The series offers various voltage ratings within the same mechanical form factor. These modules are designed for demanding industrial applications requiring reliable high-current switching. The INT-A-PAK packaging provides efficient heat dissipation through direct mounting to cold plates.
Diode Arrays Replacement Considerations
Official substitutes include other Vishay VSKD series variants with different voltage ratings such as VS-VSKD236/12PBF or VS-VSKD236/16PBF. Cross-brand replacements require verification of pinout compatibility and thermal performance metrics.
