X1005243-LGA2SA10A1

$26.98

Description：ANTENNA GPS-GLONASS/LTE
Series：-
Mfr：KYOCERA AVX
Package：Box

SKU:74925ee01749 Category: RF Antennas Brand: KYOCERA AVX

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

X1005243-LGA2SA10A1 is listed in the Antennas RF range at ChipApex. The manufacturer field lists KYOCERA AVX. Its product description is ANTENNA GPS-GLONASS/LTE. Review the specifications below when checking this part for your BOM.

Antennas RF specifications for X1005243-LGA2SA10A1

Description：ANTENNA GPS-GLONASS/LTE
Series：-
Mfr：KYOCERA AVX
Package：Box
RF Family/Standard：Cellular, Navigation
Frequency Group：Wide Band
Frequency (Center/Band)：829MHz, 1.575GHz, 1.602GHz, 1.94GHz, 2.495GHz
Frequency Range：698MHz ~ 960MHz, 1.71GHz ~ 2.17GHz, 2.3GHz ~ 2.69GHz
Antenna Type：Module
Number of Bands：5
VSWR：2, 3, 3.7
Return Loss：-
Gain：2.7dBi, 1dBi, 1dBi, 1.2dBi, 2.1dBi
Features：Cable - 1m, LNA
Termination：SMA Male (2)
Ingress Protection：IPX5
Grade：-
Qualification：-
Mounting Type：Adhesive
Height (Max)：0.413" (10.50mm)
Applications：GLONASS, GPS, LTE
Power - Max：-

Antennas RF datasheet and documents for X1005243-LGA2SA10A1

X1005243-LGA2SA10A1

Antennas RF Overview

The KYOCERA AVX X1005243-LGA2SA10A1 is a multi-band GNSS and LTE external antenna designed for global positioning and cellular connectivity. It operates across a frequency range of 698 MHz to 2690 MHz, supporting GPS, GLONASS, and LTE protocols. The unit features a square puck form factor with an adhesive mounting type and includes a 1-meter lead length terminated with a male SMA connector. It provides 2.1 dBi gain at 50 ohms impedance.

Antennas RF Feature Summary

Supports multiple satellite navigation systems including GPS and GLONASS alongside LTE bands
Utilizes a compact square puck design suitable for surface mounting via adhesive
Equipped with a pre-terminated 1-meter cable ending in a standard SMA connector

Antennas RF Applications

Automotive telematics and infotainment systems
Industrial equipment requiring location tracking
Wearable devices needing integrated positioning

Antennas RF Procurement Notes

Verify the specific datasheet revision and compliance documentation such as RoHS and REACH status before integration. Confirm that the SMA connector polarity matches your system interface requirements. Ensure the adhesive backing is compatible with the target installation surface material for reliable mechanical attachment during operation.

Antennas RF Selection Notes

Select this component when broad band coverage from sub-GHz to 2.7 GHz is required within a single compact module. The fixed 1-meter cable length dictates placement constraints relative to the host device. Consider the 2.1 dBi gain profile against other omnidirectional options if signal strength optimization is critical for the specific deployment environment.

Antennas RF Part Context

This model belongs to the X1005243 series of multi-band antennas manufactured by KYOCERA AVX. These components are engineered for applications demanding simultaneous reception of GNSS signals and LTE data. The series emphasizes space-saving designs while maintaining robust performance across diverse regulatory bands globally.
