YCGA002AA

$1.03

Description：PATCH, GNSS L1, PIN MNT, 1212
Series：-
Mfr：Quectel
Package：Tray

SKU:cde9169f84ee Category: RF Antennas Brand: Quectel

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

YCGA002AA is listed in the Antennas RF range at ChipApex. The manufacturer field lists Quectel. Its product description is PATCH, GNSS L1, PIN MNT, 1212. Review the specifications below when checking this part for your BOM.

Antennas RF specifications for YCGA002AA

Description：PATCH, GNSS L1, PIN MNT, 1212
Series：-
Mfr：Quectel
Package：Tray
RF Family/Standard：Navigation
Frequency Group：UHF (1GHz ~ 2GHz)
Frequency (Center/Band)：1.5825GHz
Frequency Range：1.559GHz ~ 1.606GHz
Antenna Type：Ceramic Patch
Number of Bands：1
VSWR：-
Return Loss：-
Gain：-
Features：-
Termination：-
Ingress Protection：-
Grade：-
Qualification：-
Mounting Type：Surface Mount
Height (Max)：0.157" (4.00mm)
Applications：GNSS, GPS
Power - Max：-

Antennas RF datasheet and documents for YCGA002AA

YCGA002AA

Antennas RF Overview

The Quectel YCGA002AA is a ceramic patch GNSS L1 antenna designed for surface mount applications. It operates within the frequency range of 1.559 GHz to 1.606 GHz, supporting GPS, GLONASS, Galileo, and Beidou systems. The component features a maximum height of 4.00 mm (0.157 inches) and utilizes pin mounting. It is RoHS3 compliant and classified as an active product suitable for compact navigation modules.

Antennas RF Feature Summary

Supports multi-constellation GNSS signals including GPS, GLONASS, Galileo, and Beidou
Compact ceramic patch design optimized for space-constrained surface mount integration
Low profile construction with a maximum height of 4.00 mm

Antennas RF Applications

GNSS receiver modules
GPS tracking devices
Navigation systems

Antennas RF Procurement Notes

Verify current availability status through authorized distributors, as supply chain conditions may affect stock levels. Confirm that the specific order suffix matches the required packaging configuration, typically supplied in reels. Ensure compliance with RoHS3 standards and check for any regional distribution restrictions before finalizing procurement orders.

Antennas RF Selection Notes

Select this component when a low-profile, surface-mountable GNSS antenna is required for L1 band reception. The 4.00 mm height constraint makes it suitable for thin form-factor designs. Verify interface compatibility with the target PCB layout and ensure the application environment does not require external connectorized solutions.

Antennas RF Part Context

This part belongs to Quectel's RF Antenna portfolio, specifically categorized under GNSS antennas for GPS, GLONASS, Galileo, and Beidou systems. It represents a passive radiating element intended for integration into electronic assemblies rather than a complete communication module.
