YEGT002BA is listed in the Antennas RF range at ChipApex. The manufacturer field lists Quectel. Its product description is GNSS TERMIANL MOUNT ANTENNA STRA. Review the specifications below when checking this part for your BOM.
Antennas RF specifications for YEGT002BA
- Description：GNSS TERMIANL MOUNT ANTENNA STRA
- Series：-
- Mfr：Quectel
- Package：Bulk
- RF Family/Standard：Navigation
- Frequency Group：UHF (1GHz ~ 2GHz)
- Frequency (Center/Band)：1.56GHz, 1.58GHz, 1.6GHz
- Frequency Range：1.56GHz ~ 1.57GHz, 1.57GHz ~ 1.58GHz, 1.59GHz ~ 1.61GHz
- Antenna Type：Whip, Straight
- Number of Bands：3
- VSWR：-
- Return Loss：-
- Gain：-
- Features：-
- Termination：SMA Male
- Ingress Protection：-
- Grade：-
- Qualification：-
- Mounting Type：-
- Height (Max)：2.047" (52.00mm)
- Applications：GNSS
- Power - Max：-
Antennas RF datasheet and documents for YEGT002BA
Antennas RF Overview
The YEGT002BA is a compact, straight terminal mount GNSS antenna manufactured by Quectel. It operates within the L1 frequency band, specifically covering 1559 MHz to 1606 MHz. The device supports multiple global navigation satellite systems including GPS, GLONASS, Galileo, and BeiDou. It features an SMA male connector for secure attachment. The antenna has a height of 52 mm and provides a gain of 1.75 dBi with a VSWR of 3. It is designed for outdoor applications requiring reliable high-performance signal reception.
Antennas RF Feature Summary
- Supports multi-constellation GNSS signals including GPS, GLONASS, Galileo, and BeiDou
- Compact straight whip design suitable for terminal mounting
- Optimized for outdoor use with reliable performance in the L1 band
Antennas RF Applications
- Outdoor mobile tracking devices
- Fleet management terminals
- Portable GNSS receivers
- Automotive navigation systems
Antennas RF Procurement Notes
Verify component authenticity through authorized distributors. Confirm that the SMA male interface matches system requirements. Ensure environmental ratings meet operational conditions. Check datasheet revisions for any updates. Validate compatibility with host module RF specifications before integration.
Antennas RF Selection Notes
Choose this model when multi-constellation support is required for L1 band applications. Consider its compact size for space-constrained designs. Evaluate outdoor durability needs against its construction. Compare gain specifications with other antennas if higher sensitivity is needed. Verify connector type compatibility with existing cable assemblies.
Antennas RF Part Context
Quectel offers various antenna solutions for IoT and connectivity modules. The YEGT002BA belongs to their GNSS antenna portfolio. It complements cellular modules like LTE and 5G series. This specific part targets applications needing precise positioning capabilities. It serves as a dedicated receiver for satellite navigation signals.
Antennas RF Replacement Considerations
Public confirmed substitute part numbers are not available in the provided documentation. Users should consult official Quectel resources for current alternatives. Direct replacements may require interface and performance verification.
