2SA1507T

Single Bipolar Transistors Overview

The Fairchild Semiconductor 2SA1507T is a PNP epitaxial silicon transistor designed for switching applications. It utilizes FBET and MBIT processes to achieve high breakdown voltage and large current capacity. The device features a plastic-covered heat sink that eliminates the need for an insulator during mounting. It is housed in a TO-126 package, suitable for color TV audio output, converters, and inverters.

Single Bipolar Transistors Feature Summary

• High breakdown voltage capability
• Large current capacity
• Adoption of FBET and MBIT process
• Plastic-covered heat sink design

Single Bipolar Transistors Applications

• Color TV audio output
• Converters
• Inverters

Single Bipolar Transistors Procurement Notes

Verify the specific manufacturer source, as ON Semiconductor also produces this part number. Confirm the datasheet aligns with the required electrical characteristics and package details before procurement. Ensure the component meets all relevant environmental standards and RoHS compliance requirements for the intended application.

Single Bipolar Transistors Selection Notes

Select this component for designs requiring robust PNP switching performance with high voltage tolerance. The integrated heat sink simplifies thermal management by removing the need for separate insulators. Consider the TO-126 package constraints and ensure the circuit design accommodates the specified current and voltage ratings for reliable operation.

Single Bipolar Transistors Part Context

The 2SA1507 series represents a class of PNP bipolar transistors optimized for general-purpose switching. Originally associated with Sanyo Semicon Device, production has been continued by ON Semiconductor. These devices are characterized by their ability to handle significant power dissipation and operate reliably in demanding electronic environments.

Single Bipolar Transistors Replacement Considerations

CPH3910-TL-E
