2SCR542F3TR

$0.91

Description：TRANS NPN 30V 3A HUML2020L3
Series：-

SKU:869dfcb5cbd2 Category: Single Bipolar Transistors Brand: Rohm Semiconductor

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

2SCR542F3TR is listed in the Single Bipolar Transistors range at ChipApex. The manufacturer field lists Rohm Semiconductor. Its product description is TRANS NPN 30V 3A HUML2020L3. Review the specifications below when checking this part for your BOM.

Single Bipolar Transistors specifications for 2SCR542F3TR

Description：TRANS NPN 30V 3A HUML2020L3
Series：-
Mfr：Rohm Semiconductor
Package：Tape & Reel (TR),Cut Tape (CT)
Transistor Type：NPN
Current - Collector (Ic) (Max)：3:00 AM
Voltage - Collector Emitter Breakdown (Max)：30 V
Vce Saturation (Max) @ Ib, Ic：200mV @ 50mA, 1A
Current - Collector Cutoff (Max)：100nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce：200 @ 500mA, 2V
Power - Max：1 W
Frequency - Transition：250MHz
Operating Temperature：150°C (TJ)
Mounting Type：Surface Mount
Package / Case：3-UDFN Exposed Pad
Supplier Device Package：HUML2020L3
Grade：-
Qualification：-

Single Bipolar Transistors datasheet and documents for 2SCR542F3TR

2SCR542F3TR

Single Bipolar Transistors Overview

The 2SCR542F3TR is an NPN middle power transistor manufactured by ROHM Semiconductor. It features a collector-emitter voltage (VCEO1) of 30V and a continuous collector current (Io/Ic) of 3.0A. The device offers a DC current gain (hFE) ranging from 200 to 500, with a minimum guaranteed hFE of 200. It is housed in a DFN2020L3 surface-mount package measuring 2.0x2.0mm with a thickness of 0.65mm. The component supports a storage temperature range from -55°C to 150°C and complies with RoHS standards.

Single Bipolar Transistors Feature Summary

Surface-mount NPN transistor designed for middle power applications
High current gain capability within the specified operating range
Compact DFN2020L3 package suitable for space-constrained designs

Single Bipolar Transistors Applications

Motor drivers
LED drivers
Power supply circuits

Single Bipolar Transistors Procurement Notes

Verify the specific ordering suffix and packaging configuration when sourcing. Confirm that the procurement channel provides genuine components directly from ROHM or authorized distributors. Ensure compliance with the stated long-term supply plan duration. Check for any regional restrictions regarding automotive usage as indicated in official documentation.

Single Bipolar Transistors Selection Notes

Select this component for applications requiring moderate current handling with high gain characteristics. The 30V rating suits low-voltage switching tasks. Consider the small footprint for dense PCB layouts. Evaluate thermal management requirements based on the 1W power dissipation limit. Ensure the operating environment stays within the specified storage temperature limits.

Single Bipolar Transistors Part Context

This part belongs to ROHM's lineup of surface-mount bipolar junction transistors. It is categorized as a standard-grade product intended for general electronic equipment. The manufacturer indicates it is not recommended for use in automotive devices. The component is currently available for purchase with a defined long-term supply plan.
