AON7820

Description：MOSFET 2N-CH 20V 8DFN
Series：-

SKU:11ba67f15ffb Category: FET, MOSFET Arrays Brand: Alpha & Omega Semiconductor Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：MOSFET 2N-CH 20V 8DFN
Series：-
Mfr：Alpha & Omega Semiconductor Inc.
Package：Tape & Reel (TR)
Technology：MOSFET (Metal Oxide)
Configuration：2 N-Channel (Dual) Common Drain
FET Feature：Logic Level Gate
Drain to Source Voltage (Vdss)：20V
Current - Continuous Drain (Id) @ 25°C：-
Rds On (Max) @ Id, Vgs：-
Vgs(th) (Max) @ Id：1V @ 250µA
Gate Charge (Qg) (Max) @ Vgs：22nC @ 4.5V
Input Capacitance (Ciss) (Max) @ Vds：2065pF @ 10V
Power - Max：3.1W
Operating Temperature：-55°C ~ 150°C (TJ)
Mounting Type：Surface Mount
Package / Case：8-PowerVDFN
Supplier Device Package：8-DFN-EP (3x3)
Grade：-
Qualification：-

Download product information

AON7820

Overview

The AON7820 is a dual N-channel MOSFET from Alpha & Omega Semiconductor, housed in an 8-DFN-EP (3x3) surface-mount package. It features a drain-source voltage of 20V and a power dissipation rating of 3.1W. The device operates within a junction temperature range of -55°C to 150°C.

Feature Summary

Dual N-channel configuration for space-efficient circuit design
Low profile 8-DFN-EP package suitable for automated assembly

Applications

DC-DC converter circuits
Power management modules
Battery protection systems

Procurement Notes

Verify the specific datasheet revision and manufacturer lot codes upon receipt. Confirm that the component matches the 8-DFN-EP (3x3) physical dimensions and electrical specifications outlined in the official Alpha & Omega Semiconductor documentation before integration into production lines.

Selection Notes

Select this component when a compact dual N-channel solution is required for low-voltage applications. The 20V rating and 3.1W thermal limit define its operational boundaries. Ensure the PCB layout supports the exposed pad thermal requirements specified in the datasheet for optimal performance.

Part Context

This part belongs to the AON series of power MOSFETs designed by Alpha & Omega Semiconductor. It provides a dual-transistor alternative to single FETs, reducing board space in portable electronics and industrial control units requiring multiple switching elements.

Replacement Considerations

Check for direct substitutes with identical pinout and electrical ratings. Verify compatibility with existing thermal management designs if replacing with higher-power variants.
