AONA66813

$2.98

Description：80V N-CHANNEL ALPHASGT2 TM
Series：AlphaSGT2™
Mfr：Alpha & Omega Semiconductor Inc.
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:6f31a9c37845 Category: Single FETs, MOSFETs Brand: Alpha & Omega Semiconductor Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

AONA66813 is listed in the Single FETs, MOSFETs range at ChipApex. The manufacturer field lists Alpha & Omega Semiconductor Inc.. Its product description is 80V N-CHANNEL ALPHASGT2 TM. Review the specifications below when checking this part for your BOM.

Single FETs, MOSFETs specifications for AONA66813

Description：80V N-CHANNEL ALPHASGT2 TM
Series：AlphaSGT2™
Mfr：Alpha & Omega Semiconductor Inc.
Package：Tape & Reel (TR),Cut Tape (CT)
FET Type：N-Channel
Technology：MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)：80 V
Current - Continuous Drain (Id) @ 25°C：40A (Ta), 216A (Tc)
Drive Voltage (Max Rds On, Min Rds On)：8V, 10V
Rds On (Max) @ Id, Vgs：2.2mOhm @ 20A, 10V
Vgs(th) (Max) @ Id：3.8V @ 250µA
Gate Charge (Qg) (Max) @ Vgs：105 nC @ 10 V
Vgs (Max)：±20V
Input Capacitance (Ciss) (Max) @ Vds：5800 pF @ 40 V
FET Feature：-
Power Dissipation (Max)：7.5W (Ta), 214W (Tc)
Operating Temperature：-55°C ~ 175°C (TJ)
Grade：-
Qualification：-
Mounting Type：Surface Mount
Supplier Device Package：8-DFN (5x6)
Package / Case：8-PowerWDFN

Single FETs, MOSFETs datasheet and documents for AONA66813

AONA66813

Single FETs, MOSFETs Overview

The AONA66813 is an N-Channel MOSFET utilizing AlphaSGT™ technology, rated for a drain-source voltage of 80V. It supports a continuous drain current of 256A at TC=25°C and features a maximum on-resistance of less than 2.2mΩ at VGS=10V. The device operates within a junction temperature range of -55°C to 175°C and is housed in a DFN5X6 package.

Single FETs, MOSFETs Feature Summary

Utilizes AlphaSGT™ technology for low on-resistance and low gate charge performance.
Features a standard level gate threshold voltage suitable for general logic-level driving applications.
Includes 100% UIS (Unclamped Inductive Switching) testing for robust operation under inductive load conditions.

Single FETs, MOSFETs Applications

DC/DC Brick Module
Synchronous Rectification

Single FETs, MOSFETs Procurement Notes

Verify the specific orderable part number and package form against the manufacturer's official documentation before procurement. Confirm that the component meets RoHS 2.0 and Halogen-Free compliance requirements as stated in the datasheet. Ensure all electrical parameters align with the intended circuit design specifications.

Single FETs, MOSFETs Selection Notes

Select this component for high-current applications requiring low conduction losses and fast switching speeds. Consider the thermal resistance values provided for both junction-to-case and junction-to-ambient configurations when designing the PCB layout. Evaluate the Safe Operating Area (SOA) curves to ensure reliable operation under varying pulse widths and duty cycles.

Single FETs, MOSFETs Part Context

This component belongs to the AlphaSGT™ family of power MOSFETs from Alpha & Omega Semiconductor Inc. It is designed for efficiency in power conversion systems. The DFN5X6 package provides a compact footprint suitable for high-density circuit designs while maintaining adequate thermal dissipation capabilities for high-current operations.
