Product Detailed Parameters
- Description：TRANS NPN/PNP 30V 100MA SOT-143B
- Series：-
- Mfr：Nexperia USA Inc.
- Package：Bulk
- Transistor Type：1 NPN, 1 PNP (Emitter Coupled)
- Current - Collector (Ic) (Max)：100mA
- Voltage - Collector Emitter Breakdown (Max)：30V
- Vce Saturation (Max) @ Ib, Ic：650mV @ 5mA, 100mA
- Current - Collector Cutoff (Max)：15nA (ICBO)
- DC Current Gain (hFE) (Min) @ Ic, Vce：75 @ 2mA, 5V
- Power - Max：250mW
- Frequency - Transition：-
- Operating Temperature：150°C (TJ)
- Mounting Type：Surface Mount
- Package / Case：TO-253-4, TO-253AA
- Supplier Device Package：SOT-143B
- Grade：Automotive
- Qualification：AEC-Q101
Download product information
Overview
The BCV65,215 is a general-purpose NPN/PNP transistor pair manufactured by Nexperia. It utilizes silicon technology and is housed in an SOT-143B surface-mount package with four terminals. The device features a maximum collector-emitter voltage of 30 V and a continuous collector current of 100 mA. Key electrical parameters include a minimum DC current gain (hFE) of 75 at VCE = 5 V and IC = 2 mA. It operates within a temperature range of -55 °C to +150 °C and has a power dissipation rating of 833 mW. The component is AEC-Q101 qualified for automotive applications.
Feature Summary
- Matched NPN/PNP pair configuration for balanced performance
- AEC-Q101 qualified for automotive reliability standards
- Low voltage and low current design suitable for signal processing
Applications
- General-purpose switching circuits
- Amplification stages in consumer electronics
- Signal conditioning in automotive zone control units
Procurement Notes
Verify the specific suffix '215' corresponds to the required tape-and-reel packaging quantity when ordering. Confirm RoHS compliance status through official Nexperia documentation prior to integration. Ensure the SOT-143B footprint matches the target PCB layout. Check for any end-of-life notices or longevity program updates directly from the manufacturer before finalizing procurement plans.
Selection Notes
Select this component when a matched NPN/PNP pair is required in a compact SMD form factor. The 30 V rating and 100 mA current limit define its operational boundaries. Consider the SOT-143B thermal characteristics for heat dissipation requirements. Verify that the hFE matching meets the circuit's symmetry needs for differential or push-pull configurations.
Part Context
The BCV65 belongs to Nexperia's portfolio of small-signal bipolar transistors designed for general-purpose applications. It is part of a series offering matched pairs in small outline packages. This family supports designs requiring compact footprints and reliable switching performance across industrial and automotive sectors.
