BSH207,135 is listed in the Single FETs, MOSFETs range at ChipApex. The manufacturer field lists Nexperia USA Inc.. Its product description is MOSFET P-CH 12V 1.52A 6TSOP. Review the specifications below when checking this part for your BOM.
Single FETs, MOSFETs specifications for BSH207,135
- Description：MOSFET P-CH 12V 1.52A 6TSOP
- Series：-
- Mfr：Nexperia USA Inc.
- Package：Bulk
- FET Type：P-Channel
- Technology：MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss)：12 V
- Current - Continuous Drain (Id) @ 25°C：1.52A (Ta)
- Drive Voltage (Max Rds On, Min Rds On)：1.8V, 4.5V
- Rds On (Max) @ Id, Vgs：120mOhm @ 1A, 4.5V
- Vgs(th) (Max) @ Id：600mV @ 1mA (Typ)
- Gate Charge (Qg) (Max) @ Vgs：8.8 nC @ 4.5 V
- Vgs (Max)：±8V
- Input Capacitance (Ciss) (Max) @ Vds：500 pF @ 9.6 V
- FET Feature：-
- Power Dissipation (Max)：417mW (Ta)
- Operating Temperature：-55°C ~ 150°C (TJ)
- Grade：-
- Qualification：-
- Mounting Type：Surface Mount
- Supplier Device Package：6-TSOP
- Package / Case：SC-74, SOT-457
