CD410899C

Diode Arrays Overview

The Powerex CD410899C is a dual diode module designed for high-power rectification applications. It features an 800 V repetitive peak reverse voltage rating and supports a 100 A average forward current. The device utilizes a series connection configuration with isolated packaging, suitable for chassis mounting. Constructed from silicon, it operates within a junction temperature range of -40°C to 125°C. The module complies with RoHS3 standards and is classified under EAR99 export control. This component provides reliable performance in industrial power conversion systems requiring robust thermal and electrical characteristics.

Diode Arrays Feature Summary

• Dual diode configuration with series connection for efficient rectification
• Isolated packaging design facilitating easy integration into chassis-mounted systems
• High thermal stability supporting operation across extended temperature ranges

Diode Arrays Applications

• Industrial power supply rectification circuits
• Motor drive inverter input stages
• DC-AC converter bridge configurations

Diode Arrays Procurement Notes

Verify the specific ordering suffix and package variant against the manufacturer's official datasheet before procurement. Confirm that the required thermal interface material compatibility matches your system design. Ensure the application voltage and current ratings do not exceed the specified 800 V and 100 A limits. Check for any recent updates to the RoHS compliance status or export classification codes. Validate lead times directly with authorized distributors as manufacturing schedules may vary.

Diode Arrays Selection Notes

Select this module when a dual diode arrangement with series connectivity is required for high-current applications. The 800 V rating makes it suitable for medium-voltage AC line rectification. Consider the isolated package style if electrical separation from the heatsink is necessary. Evaluate the 100 A continuous current capability against the expected load profile. Ensure the chassis mounting style aligns with the mechanical constraints of the target enclosure.

Diode Arrays Part Context

The CD410899C belongs to Powerex's line of discrete semiconductor modules focused on power electronics. It serves as a fundamental building block for converting alternating current to direct current in heavy-duty environments. The product family emphasizes reliability and thermal management for industrial-grade equipment. These modules are typically used in conjunction with other power semiconductors to form complete power conversion stages.

Diode Arrays Replacement Considerations

The Energitm AM-CD410899C is documented as a replacement, analogue, alternative, and equivalent semiconductor device for the Powerex CD410899C. Verify pinout compatibility and thermal resistance values before substitution.
