CPH6444-TL-W

$0.40

Description：MOSFET N-CH 60V 4.5A 6CPH
Series：-
Mfr：onsemi
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:59dd1499603d Category: Single FETs, MOSFETs Brand: onsemi

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：MOSFET N-CH 60V 4.5A 6CPH
Series：-
Mfr：onsemi
Package：Tape & Reel (TR),Cut Tape (CT)
FET Type：N-Channel
Technology：MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)：60 V
Current - Continuous Drain (Id) @ 25°C：4.5A (Ta)
Drive Voltage (Max Rds On, Min Rds On)：4V, 10V
Rds On (Max) @ Id, Vgs：78mOhm @ 2A, 10V
Vgs(th) (Max) @ Id：-
Gate Charge (Qg) (Max) @ Vgs：10 nC @ 10 V
Vgs (Max)：±20V
Input Capacitance (Ciss) (Max) @ Vds：505 pF @ 20 V
FET Feature：-
Power Dissipation (Max)：1.6W (Ta)
Operating Temperature：150°C (TJ)
Grade：-
Qualification：-
Mounting Type：Surface Mount
Supplier Device Package：6-CPH
Package / Case：SOT-23-6

Download product information

CPH6444-TL-W

Overview

The onsemi CPH6444-TL-W is a single N-channel enhancement mode Power MOSFET designed for surface-mount applications. It features a 60V drain-source breakdown voltage and supports a continuous drain current of 4.5A. The device exhibits a low on-resistance of 78mΩ, with a maximum specified at 60mΩ in some documentation contexts, ensuring efficient power handling. It operates within a temperature range of -55°C to +150°C and dissipates up to 1.6W of power. Packaged in a compact SOT-26-6 format, it utilizes silicon technology and includes standard gate-source voltage limits of ±20V.

Feature Summary

Single N-channel enhancement mode configuration for simplified circuit design
Low on-resistance characteristics for improved power efficiency
High thermal stability supporting operation up to 150°C junction temperature
Compact SMD/SMT packaging suitable for space-constrained layouts

Applications

DC-DC converter circuits
Load switching applications
Power management systems

Procurement Notes

Verify component authenticity through authorized distribution channels due to end-of-life status. Confirm RoHS and REACH compliance details prior to integration. Ensure storage conditions maintain moisture sensitivity levels appropriate for the SOT-26-6 package. Cross-reference datasheet revisions to guarantee parameter consistency with existing design specifications.

Selection Notes

Select this component for designs requiring a robust single N-channel switch with moderate current capabilities. The 60V rating suits low-voltage DC systems. Evaluate thermal dissipation requirements against the 1.6W limit. Consider the SOT-26-6 footprint compatibility during PCB layout. Compare gate charge parameters against driver capabilities for optimal switching performance.

Part Context

This part belongs to the CPH series of power MOSFETs from onsemi, focusing on small-signal and power switching applications. The series emphasizes low on-resistance and high reliability for consumer and industrial electronics. The CPH6444 variant specifically targets single-channel N-channel needs within the broader portfolio of discrete semiconductor devices.
