DCA240EB80

Overview

The DCA240EB80 is a silicon diode module manufactured by SanRex Corporation. It features an 800 V reverse voltage rating and a 240 A forward current capacity. The device utilizes a series connection configuration with one pair of diodes. It is designed for chassis mounting applications.

Feature Summary

• High current handling capability for power rectification
• Series-connected dual diode structure
• Chassis mount mechanical design

Applications

• General purpose rectifier circuits
• Industrial power conversion systems
• High current DC power supplies

Procurement Notes

Verify the specific suffix EB80 against official SanRex documentation to confirm exact electrical characteristics and pinout compatibility. Ensure thermal management solutions match the chassis mount requirements. Confirm RoHS3 compliance status through authorized distributors before finalizing procurement orders.

Selection Notes

Select this component when high voltage isolation and substantial continuous current are required in a single package. The series configuration allows for efficient voltage blocking. Evaluate thermal dissipation needs based on the 240 A rating and ensure adequate heatsinking for the chassis mount interface.

Part Context

This part belongs to the DCA series of diode arrays from SanRex. It serves as a discrete semiconductor solution for medium-to-high power electronics. The module integrates multiple chips into a robust housing suitable for industrial environments.

Replacement Considerations

The DCA240DB80 is a confirmed substitute part number within the same manufacturer's lineup, offering identical 800 V and 240 A specifications.
