Product Detailed Parameters
- Description：IGBT MODULE LOW POWER EASY
- Series：-
- Mfr：Infineon Technologies
- Package：Tray
- IGBT Type：-
- Configuration：-
- Vce(on) (Max) @ Vge, Ic：-
- Input：-
- NTC Thermistor：-
- Operating Temperature：-
- Mounting Type：-
- Package / Case：-
- Supplier Device Package：-
- Voltage - Collector Emitter Breakdown (Max)：-
- Current - Collector (Ic) (Max)：-
- Power - Max：-
- Current - Collector Cutoff (Max)：-
- Input Capacitance (Cies) @ Vce：-
Download product information
Overview
The DF150R12W1H3FB11BOMA1 is a high-speed IGBT module from Infineon Technologies, belonging to the EasyPACK™ B2A family. It features a quad configuration with a maximum collector-emitter voltage of 1200 V and a continuous collector current of 160 A at 25°C. The saturation voltage is specified at 1.55 V. Designed for press-fit mounting, it operates within a junction temperature range of -40°C to +150°C. This component utilizes trench field-stop technology to deliver low conduction and switching losses, making it suitable for demanding power conversion applications.
Feature Summary
- Integrated NTC thermistor for precise thermal monitoring
- Press-fit termination for reliable mechanical connection
- High-speed switching characteristics optimized for efficiency
Applications
- Industrial motor drives
- Uninterruptible power supplies (UPS)
- Induction heating systems
Procurement Notes
Verify the complete part number against official Infineon documentation to ensure correct suffix alignment. Confirm that the specific ordering code matches the required package variant and internal configuration. Cross-reference datasheet revisions to validate electrical parameters before integration into design specifications.
Selection Notes
Evaluate thermal management requirements based on the module's power dissipation capabilities. Ensure gate drive circuits are compatible with the specified voltage levels and switching speeds. Verify that the PCB layout supports the press-fit installation method and provides adequate clearance for the module dimensions.
Part Context
This component is part of Infineon's EasyPACK™ B2A series, designed for compact and efficient power electronics. It complements other modules in the lineup by offering a balance of high current handling and fast switching performance. The series is widely used in industrial applications requiring robust and reliable power conversion solutions.
Replacement Considerations
Consult official Infineon substitution guides for verified alternatives. Ensure any replacement maintains compatibility with the existing thermal interface and mechanical mounting constraints.
