DI2A2N100D1K-AQ

$0.49

Description：DI2A2N100D1K-AQ
Series：-
Mfr：Diotec Semiconductor
Package：Bulk

SKU:9c2476a368cf Category: Single FETs, MOSFETs Brand: Diotec Semiconductor

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：DI2A2N100D1K-AQ
Series：-
Mfr：Diotec Semiconductor
Package：Bulk
FET Type：N-Channel
Technology：MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)：1000 V
Current - Continuous Drain (Id) @ 25°C：2.2A (Tc)
Drive Voltage (Max Rds On, Min Rds On)：10V
Rds On (Max) @ Id, Vgs：6.8Ohm @ 1.5A, 10V
Vgs(th) (Max) @ Id：4V @ 250µA
Gate Charge (Qg) (Max) @ Vgs：25 nC @ 10 V
Vgs (Max)：±25V
Input Capacitance (Ciss) (Max) @ Vds：510 pF @ 25 V
FET Feature：-
Power Dissipation (Max)：30W (Tc)
Operating Temperature：-55°C ~ 150°C (TJ)
Grade：Automotive
Qualification：AEC-Q101
Mounting Type：Surface Mount
Supplier Device Package：TO-252 (DPAK)
Package / Case：TO-252-3, DPAK (2 Leads + Tab), SC-63

Download product information

DI2A2N100D1K-AQ

Overview

The DI2A2N100D1K-AQ is an N-Channel Power MOSFET from Diotec Semiconductor, housed in a TO-252AA (D-PAK) package. It features a Drain-Source voltage of 1000 V and a continuous drain current of 2.2 A at 25°C case temperature. The device has a maximum power dissipation of 30 W and a low on-state resistance of 6.8 Ω max. It supports a junction temperature up to 150°C and includes avalanche-rated characteristics with an energy rating of 125 mJ.

Feature Summary

High Drain-Source voltage capability for robust high-voltage switching applications
ESD-protected gate structure ensuring enhanced reliability during handling
Low on-state resistance to minimize conduction losses
Fast switching times suitable for efficient power conversion designs

Applications

Power Supplies
Power Factor Correction (PFC)
High Voltage DC Drives
Battery Management Systems (BMS)

Procurement Notes

Verify the specific suffix designation when ordering, as the -AQ suffix indicates the component is currently undergoing AEC-Q101 qualification rather than being fully compliant. Confirm the latest datasheet version directly with Diotec Semiconductor before finalizing design specifications to ensure all electrical parameters remain accurate.

Selection Notes

Select this component for commercial and industrial grade applications requiring high voltage isolation. Ensure thermal management strategies account for the specified thermal resistance values. Verify that the required continuous and peak drain currents align with the system's operational demands under varying case temperatures.

Part Context

This part belongs to Diotec's standard commercial/industrial grade lineup designed for general-purpose power switching. While similar to automotive-grade variants, the -AQ suffix denotes pending qualification status. It serves as a high-voltage solution within the manufacturer's broader portfolio of discrete semiconductors.
