DMN1003UCA6-7

$0.73

Description：MOSFET 2N-CH X3-DSN3518-6
Series：-

SKU:ec4c02ec8a7b Category: FET, MOSFET Arrays Brand: Diodes Incorporated

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：MOSFET 2N-CH X3-DSN3518-6
Series：-
Mfr：Diodes Incorporated
Package：Tape & Reel (TR),Cut Tape (CT)
Technology：MOSFET (Metal Oxide)
Configuration：2 N-Channel (Dual)
FET Feature：-
Drain to Source Voltage (Vdss)：-
Current - Continuous Drain (Id) @ 25°C：-
Rds On (Max) @ Id, Vgs：-
Vgs(th) (Max) @ Id：1.3V @ 1mA
Gate Charge (Qg) (Max) @ Vgs：56.5nC @ 4.5V
Input Capacitance (Ciss) (Max) @ Vds：3315pF @ 6V
Power - Max：2.67W
Operating Temperature：-55°C ~ 150°C (TJ)
Mounting Type：Surface Mount
Package / Case：6-SMD, No Lead
Supplier Device Package：X3-DSN3518-6
Grade：-
Qualification：-

Download product information

DMN1003UCA6-7

Overview

The DMN1003UCA6-7 is an N-channel enhancement mode MOSFET manufactured by Diodes Incorporated. It features a source-source configuration with a breakdown voltage of 12V and a maximum continuous source current of 23.6A at +25°C (VGS=4.5V). The device exhibits a typical on-resistance of 2.5mΩ at VGS=3.8V. Packaged in the X3-DSN3518-6 footprint measuring 3.54mm × 1.77mm with a height of 0.21mm, it supports operation from -55°C to +150°C. Total gate charge is typically 56.5nC.
