F3L400R07W3S5B11BPSA1

Overview

The F3L400R07W3S5B11BPSA1 is a six-pack IGBT module from Infineon Technologies, utilizing TRENCHSTOPIGBT7 technology within the EasyPACK 2B package. It features a collector-emitter voltage of 650 V and a continuous collector current of 100 A at 25°C. The saturation voltage is 1.17 V, with an operating temperature range from -40°C to +150°C. This silicon-based component integrates three half-bridge configurations for efficient power conversion in industrial applications.

Feature Summary

• Integrates TRENCHSTOPIGBT7 technology for optimized switching performance and low conduction losses.
• Utilizes the EasyPACK 2B modular housing design for standardized mounting and thermal management.
• Provides a six-pack configuration containing three independent half-bridge circuits within a single unit.

Applications

• Industrial motor drives and servo systems
• Uninterruptible power supplies (UPS)
• High-frequency welding inverters

Procurement Notes

Verify the specific ordering suffix against official Infineon documentation to confirm pinout compatibility and internal diode characteristics. Ensure that the requested quantity aligns with standard factory packaging constraints. Cross-reference the manufacturer part number with authorized distributor catalogs to validate authenticity and traceability before finalizing procurement orders.

Selection Notes

Select this module when a compact six-pack topology is required for 650 V applications. Compare the 1.17 V saturation voltage against alternative packages to evaluate thermal dissipation requirements. Confirm that the EasyPACK 2B footprint matches the existing PCB layout and heatsink interface specifications for seamless integration into the target power electronics design.

Part Context

This component belongs to the Infineon EasyPACK 2B family, designed for medium-power industrial applications. It succeeds earlier generations by offering improved thermal cycling robustness and higher current density. The six-pack architecture allows for cost-effective implementation of three-phase inverter stages compared to discrete solutions or larger modules.

Replacement Considerations

Direct replacements include the FS3L100R07W3S5B11BPSA1, which shares the same package and electrical ratings. Verify pin-to-pin compatibility and thermal resistance values before substituting. Consult official cross-reference lists to ensure equivalent switching speeds and gate charge characteristics are maintained.
