Product Detailed Parameters
- Description：MOSFET N-CH 650V 7.4A TO220F
- Series：SuperFET® III
- Mfr：onsemi
- Package：Tape & Reel (TR)
- FET Type：N-Channel
- Technology：MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss)：650 V
- Current - Continuous Drain (Id) @ 25°C：7.4A (Tc)
- Drive Voltage (Max Rds On, Min Rds On)：10V
- Rds On (Max) @ Id, Vgs：600mOhm @ 3.7A, 10V
- Vgs(th) (Max) @ Id：3.5V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs：26 nC @ 10 V
- Vgs (Max)：±20V
- Input Capacitance (Ciss) (Max) @ Vds：1120 pF @ 25 V
- FET Feature：-
- Power Dissipation (Max)：28W (Tc)
- Operating Temperature：-55°C ~ 150°C (TJ)
- Grade：-
- Qualification：-
- Mounting Type：Through Hole
- Supplier Device Package：TO-220F-3
- Package / Case：TO-220-3 Full Pack
Download product information
Overview
The FCPF600N60ZL1 is a discontinued N-channel SuperFET II MOSFET manufactured by onsemi. It features a TO-220-3 through-hole package and utilizes silicon technology. Key electrical parameters include a drain-source voltage of 650 V, a continuous drain current of 7.4 A, and a maximum on-resistance of 600 mΩ at 10 V gate drive. The device operates within a temperature range of -50°C to +150°C junction temperature, with a power dissipation rating of 28 W.
Feature Summary
- Integrated SuperFET II technology for optimized high-voltage performance
- Enhanced mode N-channel configuration for efficient switching
- Robust thermal management capabilities in a standard through-hole package
Applications
- High-voltage power supply circuits
- Industrial motor control systems
- General-purpose switching applications
Procurement Notes
This component has reached end-of-life status and is officially discontinued by the manufacturer. Production has ceased, meaning no new units are available from authorized distribution channels. Designers must verify availability through secondary market sources if replacement is required for existing equipment maintenance.
Selection Notes
Selection should focus on verifying the specific suffix requirements against the official datasheet, as variations may exist within the product family. Given the discontinuation status, alternative components with similar electrical ratings and pin configurations must be evaluated for compatibility. Ensure that any substitute part meets the original design's voltage, current, and thermal constraints.
Part Context
The FCPF600N60ZL1 belongs to the SuperFET II series, which integrates a logic-level gate driver with a high-voltage power MOSFET. This integration simplifies drive circuitry while maintaining low conduction losses. The device is designed for robust operation in demanding environments, offering reliable performance in single-channel configurations.
