FZ30R07W1E3B31ABOMA1

$22.91

Description：IGBT MODULE
Series：EasyPACK™

SKU:785645b28d5c Category: IGBT Modules Brand: Infineon Technologies

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：IGBT MODULE
Series：EasyPACK™
Mfr：Infineon Technologies
Package：Tray
IGBT Type：Trench Field Stop
Configuration：Single Switch
Vce(on) (Max) @ Vge, Ic：2V @ 15V, 30A
Input：Standard
NTC Thermistor：Yes
Operating Temperature：-40°C ~ 150°C (TJ)
Mounting Type：Chassis Mount
Package / Case：Module
Supplier Device Package：Module
Voltage - Collector Emitter Breakdown (Max)：650 V
Current - Collector (Ic) (Max)：45 A
Power - Max：150 W
Current - Collector Cutoff (Max)：50 µA
Input Capacitance (Cies) @ Vce：1.65 nF @ 25 V

Download product information

FZ30R07W1E3B31ABOMA1

Overview

The FZ30R07W1E3B31ABOMA1 is a single-switch IGBT module from Infineon Technologies, utilizing Trench Field Stop technology. It features a maximum collector-emitter voltage (VCEO) of 650 V and a continuous collector current (Ic) of 45 A. The device operates within a junction temperature range of -40°C to 150°C and has a maximum gate-emitter voltage of ±20 V. Packaged in the AG-EASY1B-1 format for chassis mounting, it includes an integrated NTC thermistor for thermal monitoring.

Feature Summary

Single-switch configuration with Trench Field Stop IGBT technology
Integrated NTC thermistor for precise thermal management
Automotive-grade qualification compliant with AQG 324 standards

Applications

Automotive traction inverters
On-board chargers (OBC)
DC-DC converters
Industrial motor drives

Procurement Notes

Verify the specific suffix BOMA1 against official Infineon documentation to confirm exact manufacturing lot and revision details. Ensure compatibility with AG-EASY1B-1 mounting hardware. Confirm that the integrated NTC thermistor specifications align with the system's thermal protection circuitry requirements before finalizing procurement.

Selection Notes

Select this component for applications requiring robust automotive-grade reliability and high power density. The 650 V rating suits medium-voltage systems, while the 45 A current capacity supports moderate power levels. Consider the chassis mount style for efficient heat dissipation and verify that the single-switch topology fits the circuit design constraints compared to half-bridge alternatives.

Part Context

This module belongs to Infineon's EasyPACK™ series, designed for compact and efficient power conversion. The FZ30R07W1E3B31ABOMA1 specifically targets automotive and industrial sectors where space constraints and thermal performance are critical. Its integration into the EASY family ensures standardized mechanical interfaces for easier system integration.
