Product Detailed Parameters
- Description：IC QUAD DUC CHIP MULT-STD 160BGA
- Series：-
- Mfr：Texas Instruments
- Package：Tray,Tray
- Function：Upconverter
- Frequency：-
- RF Type：CDMA, QPSK, W-CDMA
- Secondary Attributes：-
- Mounting Type：Surface Mount
- Package / Case：160-LBGA
- Supplier Device Package：160-BGA (15x15)
- Grade：-
- Qualification：-
Download product information
Overview
The GC4116-PBZ is a digital upconverter IC from Texas Instruments, integrating a complete digital upconversion chain into a single 160-ball BGA package. It supports CDMA, QPSK, and W-CDMA standards for wireless communication applications. The device converts low-frequency signals to radio frequency (RF) signals. Operating temperature ranges from -40°C to +85°C. Package dimensions are 15x15 mm.
Feature Summary
- Integrates a complete digital upconversion chain within a compact 160-ball BGA package
- Supports multiple wireless communication standards including CDMA, QPSK, and W-CDMA
- Designed for converting low-frequency signals to RF signals in wireless systems
Applications
- Wireless communication systems
- CDMA signal processing
- QPSK modulation applications
- W-CDMA infrastructure
Procurement Notes
Verify the exact part number GC4116-PBZ against official Texas Instruments documentation to ensure compatibility with specific system requirements. Confirm that the 160-ball BGA package format aligns with PCB layout constraints. Check for any specific ordering suffixes or variants if available in official catalogs. Ensure environmental ratings meet the -40°C to +85°C operating range needed for the application.
Selection Notes
Select this component when a fully integrated digital upconversion solution is required for CDMA, QPSK, or W-CDMA standards. Consider the 160-ball BGA package size of 15x15 mm for board space limitations. Evaluate thermal management capabilities given the 85°C maximum operating temperature. Compare against other wideband DDC/DUC options like the GC5016 if channel count or different functionality is needed.
Part Context
The GC4116-PBZ belongs to Texas Instruments' family of RF wireless miscellaneous ICs and modules. It is related to other devices such as the GC5016-PBZ, which offers four-channel wideband digital down-conversion and upconversion capabilities. This series targets high-performance wireless infrastructure requiring efficient signal conversion.
Replacement Considerations
Public confirmed substitute part numbers are not explicitly listed in the provided source material. For potential replacements, consult Texas Instruments official cross-reference tools or datasheets for similar digital upconverters like the GC5016-PBZ, ensuring functional and pinout compatibility.
