GSGP1R103

$1.38

Description：MOSFET, N-CH, SINGLE, 100.00A, 3
Series：-
Mfr：Good-Ark Semiconductor
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:d94be19bdac1 Category: Single FETs, MOSFETs Brand: Good-Ark Semiconductor

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

GSGP1R103 is listed in the Single FETs, MOSFETs range at ChipApex. The manufacturer field lists Good-Ark Semiconductor. Its product description is MOSFET, N-CH, SINGLE, 100.00A, 3. Review the specifications below when checking this part for your BOM.

Single FETs, MOSFETs specifications for GSGP1R103

Description：MOSFET, N-CH, SINGLE, 100.00A, 3
Series：-
Mfr：Good-Ark Semiconductor
Package：Tape & Reel (TR),Cut Tape (CT)
FET Type：N-Channel
Technology：MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)：30 V
Current - Continuous Drain (Id) @ 25°C：100A (Tc)
Drive Voltage (Max Rds On, Min Rds On)：10V
Rds On (Max) @ Id, Vgs：1.1mOhm @ 30A, 10V
Vgs(th) (Max) @ Id：2.3V @ 250µA
Gate Charge (Qg) (Max) @ Vgs：40 nC @ 4.5 V
Vgs (Max)：±20V
Input Capacitance (Ciss) (Max) @ Vds：5900 pF @ 15 V
FET Feature：-
Power Dissipation (Max)：93W (Tc)
Operating Temperature：-55°C ~ 150°C (TJ)
Grade：-
Qualification：-
Mounting Type：Surface Mount
Supplier Device Package：8-PPAK (5.1x5.86)
Package / Case：8-PowerTDFN

Single FETs, MOSFETs datasheet and documents for GSGP1R103

GSGP1R103

Single FETs, MOSFETs Overview

The GSGP1R103 is a 30V N-Channel MOSFET from Good-Ark Semiconductor, designed for high-efficiency switched-mode power supplies. It features an advanced MOSFET process technology that achieves high cell density and low on-resistance. The device offers a maximum drain-source voltage (BVDSS) of 30V and a continuous drain current (ID) of 100A at steady-state conditions. Its maximum static drain-source on-resistance (RDS(ON)) is 1.1mΩ. The component utilizes the PPAK5x6 package.

Single FETs, MOSFETs Feature Summary

Advanced MOSFET process technology for high cell density
Low on-resistance combined with low gate charge
Fast switching capabilities with reverse body recovery

Single FETs, MOSFETs Applications

High efficiency switched mode power supplies
General purpose power applications requiring fast switching

Single FETs, MOSFETs Procurement Notes

Verify the specific ordering suffix and carrier quantity when purchasing. Confirm the tape and reel packaging details match the required manufacturing equipment specifications. Ensure the component marking aligns with the datasheet documentation to guarantee authenticity and traceability during the procurement process.

Single FETs, MOSFETs Selection Notes

Select this component based on its 30V breakdown voltage and 100A continuous current rating. Evaluate the thermal resistance characteristics against the expected operating junction temperature. Consider the gate charge parameters for driving requirements in high-frequency switching environments.

Single FETs, MOSFETs Part Context

This part belongs to the N-Channel MOSFET category manufactured by Good-Ark Semiconductor. It is housed in a PPAK5x6 surface-mount package. The device is optimized for applications demanding high efficiency and reliability through its specialized process technology.
