ISA150233C03LMDSXTMA

$1.49

Description：ISA150233C03LMDSXTMA
Series：OptiMOS™ 3

SKU:71296458075d Category: FET, MOSFET Arrays Brand: Infineon Technologies

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

ISA150233C03LMDSXTMA is listed in the FET, MOSFET Arrays range at ChipApex. The manufacturer field lists Infineon Technologies. Its product description is ISA150233C03LMDSXTMA. Review the specifications below when checking this part for your BOM.

FET, MOSFET Arrays specifications for ISA150233C03LMDSXTMA

Description：ISA150233C03LMDSXTMA
Series：OptiMOS™ 3
Mfr：Infineon Technologies
Package：Tape & Reel (TR),Cut Tape (CT)
Technology：MOSFET (Metal Oxide)
Configuration：N and P-Channel
FET Feature：-
Drain to Source Voltage (Vdss)：30V
Current - Continuous Drain (Id) @ 25°C：7.6A (Ta), 10.2A (Tc), 6.6A (Ta), 8.8A (Tc)
Rds On (Max) @ Id, Vgs：15mOhm @ 10.2A, 10V, 23.3mOhm @ 8.8A, 10V
Vgs(th) (Max) @ Id：2.7V @ 1mA
Gate Charge (Qg) (Max) @ Vgs：19nC @ 10V, 32nC @ 10V
Input Capacitance (Ciss) (Max) @ Vds：1300pF @ 15V, 2300pF @ 15V
Power - Max：1.4W (Ta), 2.5W (Tc)
Operating Temperature：-55°C ~ 150°C (TJ)
Mounting Type：Surface Mount
Package / Case：8-SOIC (0.154", 3.90mm Width)
Supplier Device Package：PG-DSO-8-920
Grade：-
Qualification：-

FET, MOSFET Arrays datasheet and documents for ISA150233C03LMDSXTMA

ISA150233C03LMDSXTMA

FET, MOSFET Arrays Overview

The ISA150233C03LMDS is a complementary N- and P-channel MOSFET from the OptiMOS 3 Power Transistors family, rated at 30 V. It features an R_DS(on) of 15 mΩ for the N-channel with I_D of 10.2 A, and 23.3 mΩ for the P-channel with I_D of -8.8 A. The device operates within a temperature range of -55 °C to +150 °C and utilizes a PG-DSO-8 package.

FET, MOSFET Arrays Feature Summary

Complementary N- and P-channel configuration
Very low on-resistance R_DS(on)
Superior thermal resistance
100% avalanche tested

FET, MOSFET Arrays Applications

Power management circuits
Motor control applications
Industrial power supplies

FET, MOSFET Arrays Procurement Notes

Verify component authenticity by checking the marking code '1523C03L' against official Infineon documentation. Confirm compliance with RoHS standards and halogen-free requirements per IEC61249-2-21. Ensure ordering suffixes match the exact datasheet specifications to avoid functional discrepancies.

FET, MOSFET Arrays Selection Notes

Select this component for designs requiring low on-resistance and high current handling in a compact surface-mount format. Consider the thermal characteristics and safe operating area when designing heat dissipation strategies. Verify gate threshold voltage compatibility with the driving logic levels.

FET, MOSFET Arrays Part Context

This part belongs to the OptiMOS 3 Power Transistors series, designed for general-purpose power switching applications. It integrates both N-channel and P-channel technologies into a single package to simplify circuit design and reduce board space requirements.

FET, MOSFET Arrays Replacement Considerations

Consult official Infineon cross-reference tools for verified substitutes. Do not assume pin-compatible alternatives without verifying electrical parameters and thermal performance against the original datasheet.
