LFE2M50SE-6F900C

Field Programmable Gate Array Overview

The LFE2M50SE-6F900C is a member of the LatticeECP2/M family, an embedded FPGA IC featuring 48000 logic elements and 270 I/Os. It utilizes a 484-BBGA package with dimensions of 23x23 mm. The device operates on a supply voltage range of 1.14V to 1.26V and supports a total RAM capacity of 4246528 bits. It contains 6000 LAB/CLBs and includes up to 35 sysDSP blocks for high-performance multiply and accumulate operations. The component is designed for surface mount installation.

Field Programmable Gate Array Feature Summary

• Supports pre-engineered source synchronous I/O standards including SPI4.2 and SFI4.
• Features dedicated DDR and DDR2 memory support with specific gearing logic.
• Includes programmable sysI/O buffers compatible with multiple interface standards.

Field Programmable Gate Array Applications

• High-speed ADC/DAC interfacing
• Embedded vision systems
• Industrial automation control

Field Programmable Gate Array Procurement Notes

Verify the exact suffix against official Lattice documentation to confirm temperature grade and package variant. Confirm availability through authorized distributors as lead times may vary. Ensure compatibility with Diamond software tools for programming and configuration before procurement.

Field Programmable Gate Array Selection Notes

Select this model when system requirements align with the ECP2M architecture's specific logic density and I/O count. Evaluate power consumption profiles against the 1.14V to 1.26V operating range. Consider the 484-ball BGA footprint constraints during PCB layout planning.

Field Programmable Gate Array Part Context

This component belongs to the LatticeECP2/M series, which bridges low-power and high-density FPGA markets. It shares architectural similarities with other ECP2M devices but offers distinct resource configurations. The family is known for supporting advanced serial interfaces and embedded processing capabilities.

Field Programmable Gate Array Replacement Considerations

LFE2M50E-6FN484I is a documented related part within the same family. Verify pinout and package compatibility before substitution. Cross-reference datasheet DS1006 for detailed electrical parameter matching.
