M80-4000000FD-03-301-00-000

Headers, Receptacles, Female Sockets Overview

The Harwin M80-4000000FD-03-301-00-000 is a Datamate Mix-Tek female cable connector designed for power-to-board applications. It features an extended guide pin and includes three +2mm crimp coax contacts arranged at a 90-degree angle. The unit is specified without signal contacts and utilizes jackscrews for secure mounting. Constructed with a black insulator, this socket-type component belongs to the M80 series of power connectors, offering a robust solution for high-current interconnect requirements in industrial and electronic systems.

Headers, Receptacles, Female Sockets Feature Summary

• Integrates three +2mm crimp coax contacts for high-current power transmission
• Features a 90-degree angled contact orientation for compact cable routing
• Includes an extended guide pin to ensure precise mating alignment
• Utilizes jackscrew mounting for secure panel or chassis attachment

Headers, Receptacles, Female Sockets Applications

• Industrial control system power distribution
• Electronic equipment internal power interconnects
• High-current board-to-cable connections
• Power supply module interfaces

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific ordering suffix against the official Harwin datasheet to confirm contact configuration and housing material. Ensure compatibility with mating male counterparts within the Datamate Mix-Tek series. Confirm that the +2mm coax contact specification meets the required current carrying capacity for the intended application before finalizing procurement orders.

Headers, Receptacles, Female Sockets Selection Notes

Select this connector when high-current power delivery is required alongside mechanical stability provided by jackscrews. The 90-degree coax contacts are suitable for applications needing flexible cable management. Ensure the mating environment supports the mixed-signal nature of the Mix-Tek series if signal contacts are added later. Verify space constraints accommodate the extended guide pin length.

Headers, Receptacles, Female Sockets Part Context

This component is part of the Harwin Datamate Mix-Tek family, which combines power and signal capabilities in a single connector system. The M80 series is known for its durability and high current handling. This specific female cable variant complements male board connectors, forming a complete interconnect solution for demanding power applications.

Headers, Receptacles, Female Sockets Replacement Considerations

Direct substitutes must match the Datamate Mix-Tek form factor and +2mm coax contact size. Verify that any alternative maintains the 90-degree contact angle and jackscrew mounting style. Cross-reference pin counts and guide pin specifications to ensure mechanical interchangeability without redesigning the enclosure or cable assembly.
