MAX2880ETP+T

Overview

The MAX2880ETP+T is a high-performance phase-locked loop (PLL) synthesizer manufactured by Analog Devices Inc./Maxim Integrated. It operates in both integer-N and fractional-N modes, supporting frequencies up to 12.6 GHz. The device is housed in a compact 20-TQFN (4x4 mm) package with an exposed pad for thermal management. Designed for general-purpose RF applications, it integrates a voltage-controlled oscillator (VCO) and requires an external reference input. The component utilizes silicon technology and is suitable for wireless communication systems requiring precise frequency synthesis.

Feature Summary

• Supports both integer-N and fractional-N PLL operation modes for flexible frequency synthesis
• Integrates a high-performance VCO covering a wide output frequency range up to 12.6 GHz
• Compact surface-mount packaging facilitates dense PCB layout in portable devices

Applications

• Wireless local area network (WLAN) transceivers
• Bluetooth and Zigbee communication modules
• General-purpose RF signal generation systems

Procurement Notes

Verify the specific suffix 'ETP+T' against official Analog Devices documentation to confirm the tape-and-reel packaging configuration. Ensure compatibility with the required operating temperature range and supply voltage specifications before integration. Cross-reference the RoHS compliance status with the latest manufacturer datasheet to meet environmental regulations.

Selection Notes

Select this component when a single-chip solution for wideband frequency synthesis is required without external VCOs. Consider the 20-TQFN package size for space-constrained designs. Evaluate the need for fractional-N mode capabilities to achieve fine frequency resolution compared to standard integer-N synthesizers.

Part Context

This part belongs to the Maxim Integrated RF IC portfolio, specifically designed for wireless connectivity applications. It complements other baseband and power management components in modern mobile and IoT device architectures. The series focuses on integrating complex RF functions into minimal footprints to reduce system cost and complexity.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided source material.
