MBR3035PT-E3/45

Diode Arrays Overview

The MBR3035PT-E3/45 is a dual common-cathode Schottky barrier rectifier manufactured by Vishay General Semiconductor - Diodes Division. It features a maximum repetitive peak reverse voltage of 35 V and an average forward rectified current of 30 A per leg. The device utilizes a low-profile TO-263AB (D2PAK) surface-mount package, designed for high current density applications. Key electrical characteristics include a maximum DC junction operating temperature range of -65°C to 150°C and a non-repetitive peak surge forward current rating of 200 A. The component is RoHS compliant and lead-free.

Diode Arrays Feature Summary

• Dual common-cathode configuration for efficient bridge or freewheeling circuit topologies
• Low forward voltage drop characteristic to minimize conduction losses
• High current density capability in a compact surface-mount package
• Robust thermal performance suitable for demanding power conversion environments

Diode Arrays Applications

• DC-DC converters
• Free-wheeling diodes in synchronous rectification circuits
• Power factor correction (PFC) circuits
• Isolated DC/DC converter outputs

Diode Arrays Procurement Notes

Verify the obsolete status of this specific part number before procurement planning. Check for active manufacturer recommendations or approved pin-compatible alternatives that maintain identical electrical specifications and thermal characteristics. Ensure supply chain continuity strategies account for potential discontinuation risks associated with legacy components.

Diode Arrays Selection Notes

Select this component for applications requiring high current handling in a surface-mount format where low forward voltage drop is critical for efficiency. Consider the thermal resistance of the D2PAK package and ensure adequate PCB copper area for heat dissipation. Verify that the 35 V reverse voltage rating provides sufficient margin for the specific circuit's peak inverse voltage requirements.

Diode Arrays Part Context

This component belongs to Vishay's MBR series of high current density Schottky rectifiers. The 'PT' suffix indicates a dual common-cathode configuration in a TO-263AB package. The '-E3' designation signifies compliance with RoHS directives and lead-free manufacturing processes, aligning with modern environmental standards for electronic components.

Diode Arrays Replacement Considerations

The MBR3035PT-E3/45 is officially listed as obsolete and no longer manufactured. Users should consult Vishay's official documentation for recommended replacement parts or equivalent devices from other manufacturers that match the 30A/35V dual common-cathode specification and TO-263AB footprint.
