MCS2305B-TP-HF is listed in the Single FETs, MOSFETs range at ChipApex. The manufacturer field lists MCC (Micro Commercial Components). Its product description is IC. Review the specifications below when checking this part for your BOM.
Single FETs, MOSFETs specifications for MCS2305B-TP-HF
- Description：IC
- Series：-
- Mfr：MCC (Micro Commercial Components)
- Package：Tape & Reel (TR)
- FET Type：P-Channel
- Technology：MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss)：20 V
- Current - Continuous Drain (Id) @ 25°C：8.2A
- Drive Voltage (Max Rds On, Min Rds On)：1.8V, 4.5V
- Rds On (Max) @ Id, Vgs：8.5mOhm @ 4.2A, 4.5V
- Vgs(th) (Max) @ Id：900mV @ 250µA
- Gate Charge (Qg) (Max) @ Vgs：55 nC @ 10 V
- Vgs (Max)：±8V
- Input Capacitance (Ciss) (Max) @ Vds：5592 pF @ 10 V
- FET Feature：-
- Power Dissipation (Max)：1.04W (Tj)
- Operating Temperature：-55°C ~ 150°C (TJ)
- Grade：-
- Qualification：-
- Mounting Type：Surface Mount
- Supplier Device Package：8-TSSOP
- Package / Case：8-TSSOP (0.173", 4.40mm Width)
Single FETs, MOSFETs datasheet and documents for MCS2305B-TP-HF
Single FETs, MOSFETs Overview
The MCS2305B-TP-HF is a P-Channel Power MOSFET manufactured by Micro Commercial Components. It features an 8-TSSOP surface-mount package and supports a drain-source voltage of 20 V. The device handles a continuous current of 8.2 A at junction temperature, with a power dissipation rating of 1.04 W to 1.05 W. It operates with a gate-source voltage threshold of 8 V and exhibits a gate charge of 290 pF.
Single FETs, MOSFETs Feature Summary
- P-Channel trench technology for efficient switching
- Surface mount construction in compact 8-TSSOP package
- Halogen-free compliant manufacturing
Single FETs, MOSFETs Applications
- DC-DC converter circuits
- Power management modules
- Battery protection systems
Single FETs, MOSFETs Procurement Notes
Verify the exact suffix against the manufacturer's official documentation to confirm halogen-free status and packaging quantity. Ensure the ordering part number matches the specific tape and reel configuration required for your assembly line. Cross-reference the datasheet revision date to guarantee compatibility with current design specifications.
Single FETs, MOSFETs Selection Notes
Select this component when a low-voltage P-channel switch is required in a small footprint. The 8-TSSOP package suits automated surface-mount processes. Confirm that the 20 V rating aligns with the system's maximum operating voltage and that the thermal resistance supports the expected power dissipation in the final enclosure.
Single FETs, MOSFETs Part Context
This part belongs to the MCS2305B series from Micro Commercial Components. The -HF suffix specifically denotes a halogen-free variant of the standard MCS2305B-TP. It is designed as a direct replacement for similar industry-standard P-channel MOSFETs in space-constrained applications requiring reliable switching performance.
Single FETs, MOSFETs Replacement Considerations
The standard MCS2305B-TP serves as the non-halogen-free equivalent. Verify pinout compatibility before substitution. No other public substitute part numbers are confirmed in the provided documentation.
