MD1690A-DKM2MM

$36.09

Description：DIODE MODULE GP 1600V 90A A3
Series：-

SKU:540b9157472c Category: Diode Arrays Brand: Littelfuse Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：DIODE MODULE GP 1600V 90A A3
Series：-
Mfr：Littelfuse Inc.
Package：Bulk
Diode Configuration：1 Pair Common Cathode
Technology：Standard
Voltage - DC Reverse (Vr) (Max)：1600 V
Current - Average Rectified (Io) (per Diode)：90A
Voltage - Forward (Vf) (Max) @ If：1.6 V @ 280 A
Speed：Standard Recovery >500ns, > 200mA (Io)
Reverse Recovery Time (trr)：-
Current - Reverse Leakage @ Vr：500 µA @ 1600 V
Operating Temperature - Junction：-40°C ~ 150°C
Mounting Type：Chassis Mount
Package / Case：A-3 Module
Supplier Device Package：A3
Grade：-
Qualification：-

Download product information

MD1690A-DKM2MM

Overview

The MD1690A-DKM2MM is a silicon rectifier diode module manufactured by Littelfuse Inc. It features a dual common cathode configuration housed in a compact A3 package with screw mounting. The device supports a reverse voltage of 1.6 kV and an output current of 90 A. It operates within a temperature range of -40°C to +150°C and exhibits a maximum forward voltage of 1.6 V. This component is designed for high-voltage and high-current industrial applications.

Feature Summary

Dual common cathode topology for phase leg or rectification circuits
Low reverse recovery loss and low forward voltage characteristics
High surge current capability with low inductance packaging
Screw mount design for secure electrical installation

Applications

Industrial power conversion systems
General-purpose high-voltage rectification
High-voltage regulated power supplies

Procurement Notes

Verify the specific ordering suffix DKM2MM against official Littelfuse documentation to ensure correct pinout and thermal specifications. Confirm that the active lifecycle status remains unchanged prior to procurement. Check for any regional shipping restrictions, as availability may vary by sales area. Ensure compatibility with existing cooling and mounting infrastructure before finalizing orders.

Selection Notes

Select this module for applications requiring robust high-voltage handling and significant current capacity. The dual common cathode arrangement simplifies circuit design for three-phase or full-bridge configurations. Consider the screw-mount style for mechanical stability in high-vibration environments. Evaluate thermal management requirements based on the 90 A continuous current rating and operating temperature limits.

Part Context

This component belongs to the Littelfuse Diode Power Modules series, specifically designed for general-purpose high-voltage and high-current applications. It utilizes silicon technology to deliver reliable performance in demanding industrial settings. The product is currently listed under an active lifecycle status, indicating ongoing manufacturing support.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided source material. Consult Littelfuse technical resources for potential cross-references or updated model equivalents.
