Product Detailed Parameters
- Description：IGBT MODULES
- Series：-
- Mfr：MCC (Micro Commercial Components)
- Package：Tape & Reel (TR)
- IGBT Type：-
- Configuration：Three Phase Inverter
- Vce(on) (Max) @ Vge, Ic：2.05V @ 15V, 40A
- Input：Three Phase Bridge Rectifier
- NTC Thermistor：Yes
- Operating Temperature：175°C (TJ)
- Mounting Type：Chassis Mount
- Package / Case：Module
- Supplier Device Package：-
- Voltage - Collector Emitter Breakdown (Max)：1200 V
- Current - Collector (Ic) (Max)：40 A
- Power - Max：227 W
- Current - Collector Cutoff (Max)：1 mA
- Input Capacitance (Cies) @ Vce：2250 pF @ 25 V
Download product information
Overview
The MIP40R12E1TN is a 1200V, 40A IGBT module manufactured by Micro Commercial Components. It integrates an inverter leg, a brake-chopper switch with anti-parallel diode, and a rectifier diode. The device supports a maximum junction temperature of 175°C and includes an NTC thermistor for thermal monitoring. Key electrical parameters include a collector-emitter saturation voltage of 2.05V at 25°C and a short-circuit withstand capability of 200A for 10μs. The module features low stray inductance (60nH) and RoHS compliance.
Feature Summary
- Integrates IGBT inverter, brake-chopper, and rectifier functions within a single package
- Includes fast and soft recovery anti-parallel freewheeling diodes
- Features low inductance case design to minimize switching losses
- Incorporates an NTC thermistor for precise junction temperature monitoring
Applications
- Motor Drivers
- AC and DC Servo Drive Amplifiers
- Uninterruptible Power Supplies (UPS)
Procurement Notes
Verify the authenticity of the component through authorized MCC distributors or direct procurement channels. Ensure the ordering suffix matches the required specifications, as the 'BP' designation indicates specific packaging configurations. Confirm that the received parts meet the RoHS compliance standards and UL 94 V-0 flammability ratings specified in the datasheet before integration into final assemblies.
Selection Notes
Select this module for applications requiring integrated braking and rectification capabilities alongside standard inversion. The 175°C maximum junction temperature allows for operation in high-thermal environments. Consider the 60nH stray inductance for high-frequency switching designs. Verify that the gate drive requirements align with the specified threshold voltages and charge characteristics for optimal performance.
Part Context
This component belongs to the MIP series of IGBT modules from Micro Commercial Components. It is designed for medium-power industrial applications where space efficiency and thermal management are critical. The inclusion of multiple functional blocks reduces the overall system footprint compared to discrete solutions.
Replacement Considerations
No public confirmed substitute part numbers are available in the provided documentation. Engineers should verify pin compatibility and electrical parameter overlaps when considering alternative manufacturers.
FAQ
What is the short-circuit withstand time for the IGBT?
The module has a short-circuit withstand capability of 10 microseconds.
Does the module include thermal protection components?
Yes, the module integrates an NTC thermistor for monitoring the junction temperature.
What is the maximum operating junction temperature?
The maximum operating junction temperature is 175°C.
