MRF455

$51.47

Description：RF TRANS NPN 18V 211-07
Series：-

SKU:de2fb39c20c2 Category: Bipolar RF Transistors Brand: MACOM Technology Solutions

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：RF TRANS NPN 18V 211-07
Series：-
Mfr：MACOM Technology Solutions
Package：Tray
Transistor Type：NPN
Voltage - Collector Emitter Breakdown (Max)：18V
Frequency - Transition：-
Noise Figure (dB Typ @ f)：-
Gain：13dB
Power - Max：60W
DC Current Gain (hFE) (Min) @ Ic, Vce：10 @ 5A, 5V
Current - Collector (Ic) (Max)：15A
Operating Temperature：-
Mounting Type：Chassis Mount
Package / Case：211-07
Supplier Device Package：211-07, STYLE 1
Grade：-
Qualification：-

Download product information

MRF455

Overview

The MRF455 is an NPN silicon power transistor designed for RF power amplifier applications up to 30 MHz. It delivers a guaranteed output power of 60 W at 12.5 V with a minimum gain of 13 dB and efficiency of 55%. The device features a collector-emitter breakdown voltage of 18 Vdc, continuous collector current of 15 Adc, and total device dissipation of 175 W at 25°C case temperature. It utilizes gold metallization for high reliability and is housed in a ceramic flange package.

Feature Summary

Gold metallization system ensures high reliability for demanding environments
Optimized for guaranteed performance at 30 MHz operation
Designed specifically for industrial, commercial, and amateur radio equipment

Applications

Aerospace & Defense
Industrial, Scientific, and Medical (ISM)
Amateur Radio Equipment

Procurement Notes

Verify the specific revision status against the latest MACOM datasheet before procurement. Confirm that the application environment remains within the specified thermal limits, as sustained operation near maximum survivability limits is not recommended by the manufacturer. Ensure proper grounding and thermal management are implemented during installation.

Selection Notes

Select this component for linear or saturated power amplifier designs operating strictly below 30 MHz. Evaluate the required heat sinking capabilities carefully, given the 175 W dissipation rating at 25°C case temperature. Consider the input and output impedance values provided in the functional test section for accurate matching network design.

Part Context

This part belongs to MACOM's RF Line series of bipolar RF transistors. These devices are engineered for high-performance power amplification in the HF band. The MRF455 serves as a robust solution for legacy and specialized communication systems requiring high power density and reliability in compact form factors.

Replacement Considerations

Consult MACOM documentation for direct replacements. Verify pinout compatibility and thermal resistance specifications when substituting with other RF power transistors from different manufacturers.
