NVMFS5C423NLWFAFT1G

$1.94

Description：MOSFET N-CH 40V 31A/150A 5DFN
Series：-
Mfr：onsemi
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:f594f748fac4 Category: Single FETs, MOSFETs Brand: onsemi

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

NVMFS5C423NLWFAFT1G is listed in the Single FETs, MOSFETs range at ChipApex. The manufacturer field lists onsemi. Its product description is MOSFET N-CH 40V 31A/150A 5DFN. Review the specifications below when checking this part for your BOM.

Single FETs, MOSFETs specifications for NVMFS5C423NLWFAFT1G

Description：MOSFET N-CH 40V 31A/150A 5DFN
Series：-
Mfr：onsemi
Package：Tape & Reel (TR),Cut Tape (CT)
FET Type：N-Channel
Technology：MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)：40 V
Current - Continuous Drain (Id) @ 25°C：31A (Ta), 150A (Tc)
Drive Voltage (Max Rds On, Min Rds On)：4.5V, 10V
Rds On (Max) @ Id, Vgs：2mOhm @ 50A, 10V
Vgs(th) (Max) @ Id：2V @ 250µA
Gate Charge (Qg) (Max) @ Vgs：50 nC @ 10 V
Vgs (Max)：±20V
Input Capacitance (Ciss) (Max) @ Vds：3100 pF @ 20 V
FET Feature：-
Power Dissipation (Max)：3.7W (Ta), 83W (Tc)
Operating Temperature：-55°C ~ 175°C (TJ)
Grade：Automotive
Qualification：AEC-Q101
Mounting Type：Surface Mount, Wettable Flank
Supplier Device Package：5-DFN (5x6) (8-SOFL)
Package / Case：8-PowerTDFN, 5 Leads

Single FETs, MOSFETs datasheet and documents for NVMFS5C423NLWFAFT1G

NVMFS5C423NLWFAFT1G

Single FETs, MOSFETs Overview

The NVMFS5C423NLWFAFT1G is a single N-channel power MOSFET from onsemi, housed in a DFN5 (SO-8FL) package with wettable flank options. It features a 40 V drain-to-source voltage rating and supports a continuous drain current of 150 A at 25 °C case temperature. The device exhibits a maximum on-resistance of 2.0 mΩ at 10 V gate drive and 3.0 mΩ at 4.5 V. Total gate charge reaches 50 nC at 10 V. It operates within a junction temperature range of -55 °C to +175 °C and holds AEC-Q101 qualification.

Single FETs, MOSFETs Feature Summary

Small footprint design for compact applications
Low on-resistance to minimize conduction losses
Low gate charge and capacitance to reduce driver losses
Wettable flank option for enhanced optical inspection

Single FETs, MOSFETs Applications

Automotive electronics requiring AEC-Q101 compliance
Power conversion systems minimizing conduction losses
Applications demanding compact PCB layouts

Single FETs, MOSFETs Procurement Notes

Verify the specific suffix 'W' confirms the inclusion of wettable flanks for improved solder joint visibility during automated optical inspection. Confirm the 'AFT1G' designation indicates tape and reel packaging containing 1500 units per reel. Ensure the component meets RoHS standards and lead-free requirements as specified by the manufacturer.

Single FETs, MOSFETs Selection Notes

Select this component when a 40 V rating is sufficient and low on-resistance is critical for efficiency. The wettable flank variant facilitates reliable surface mount assembly and quality control. Consider the thermal resistance characteristics and ensure adequate heat dissipation for the intended continuous current load.

Single FETs, MOSFETs Part Context

This part belongs to the NVMFS5C423NL series of single N-channel power MOSFETs. It utilizes silicon technology and is designed for high-current applications. The device is manufactured by onsemi and is available in a DFN5 package configuration suitable for surface mounting.
