PCHMB200W12

$92.01

Description：IGBT MODULE, 1IN1, CHOPPER CIRCU
Series：-

SKU:cbef22b02e90 Category: IGBT Modules Brand: KYOCERA AVX

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：IGBT MODULE, 1IN1, CHOPPER CIRCU
Series：-
Mfr：KYOCERA AVX
Package：Bulk
IGBT Type：-
Configuration：Single
Vce(on) (Max) @ Vge, Ic：2V @ 15V, 200A
Input：Standard
NTC Thermistor：No
Operating Temperature：-40°C ~ 150°C (TJ)
Mounting Type：Chassis Mount
Package / Case：Module
Supplier Device Package：Module
Voltage - Collector Emitter Breakdown (Max)：1200 V
Current - Collector (Ic) (Max)：200 A
Power - Max：961 W
Current - Collector Cutoff (Max)：1 mA
Input Capacitance (Cies) @ Vce：19000 pF @ 25 V

Download product information

PCHMB200W12

Overview

The PCHMB200W12 is a single IGBT module manufactured by KYOCERA AVX, designed for high-power switching applications. It features a 1200 V collector-emitter voltage rating and a continuous collector current capacity of 200 A. The device incorporates an integrated Fast Recovery Diode (FRD) within a one-in-one chopper circuit topology. With a power dissipation rating of 961 W, this component is engineered for robust thermal performance in chassis mount configurations, suitable for demanding industrial and traction environments requiring reliable high-voltage semiconductor switching.

Feature Summary

Integrates an IGBT switch with a complementary Fast Recovery Diode in a single package
Engineered for high-power chopper circuit topologies
Designed for chassis mounting to support heavy-duty thermal management

Applications

Industrial motor drives
Traction inverters
Chopper circuits for DC-DC conversion

Procurement Notes

Verify the specific datasheet revision and ordering suffixes directly with authorized distributors or KYOCERA AVX sales representatives. Confirm that the mechanical dimensions and terminal configurations match your PCB or chassis design requirements before finalizing procurement orders to ensure compatibility.

Selection Notes

Select this module when a combined IGBT and FRD solution is required for high-current applications up to 200 A. Ensure the thermal interface material and heatsink design can handle the specified 961 W power dissipation. Evaluate the switching speed requirements against the integrated diode characteristics to optimize system efficiency and minimize electromagnetic interference.

Part Context

This component belongs to the PCHMB series of IGBT modules from KYOCERA AVX. These modules are part of a broader portfolio of power semiconductor devices aimed at providing efficient solutions for power electronics. The series typically includes various voltage and current ratings to accommodate different power levels in industrial and automotive sectors.

Replacement Considerations

Consult official substitution lists for compatible alternatives such as the PCFMB200W12. Verify pinout compatibility and electrical specifications before replacing components to maintain system integrity.
