PMDPB70EN,115

$0.17

Description：MOSFET 2N-CH 30V 3.5A 6HUSON
Series：-

SKU:1e2b0157ec6b Category: FET, MOSFET Arrays Brand: Nexperia USA Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：MOSFET 2N-CH 30V 3.5A 6HUSON
Series：-
Mfr：Nexperia USA Inc.
Package：Bulk
Technology：MOSFET (Metal Oxide)
Configuration：2 N-Channel (Dual)
FET Feature：Logic Level Gate
Drain to Source Voltage (Vdss)：30V
Current - Continuous Drain (Id) @ 25°C：3.5A
Rds On (Max) @ Id, Vgs：57mOhm @ 3.5A, 10V
Vgs(th) (Max) @ Id：2.5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs：4.5nC @ 10V
Input Capacitance (Ciss) (Max) @ Vds：130pF @ 15V
Power - Max：510mW
Operating Temperature：-55°C ~ 150°C (TJ)
Mounting Type：Surface Mount
Package / Case：6-UFDFN Exposed Pad
Supplier Device Package：6-HUSON (2x2)
Grade：-
Qualification：-

Download product information

PMDPB70EN,115

Overview

The PMDPB70EN,115 is a dual P-channel enhancement-mode MOSFET manufactured by Nexperia. It features a maximum drain-source voltage of 20 V and a continuous drain current of 4.2 A. The device exhibits a low on-state resistance of 66 mΩ at a gate-source voltage of -4.5 V. Packaged in a DFN-2020-6 (SOT1118) surface-mount housing, it supports a power dissipation of 8.33 W. Operating temperatures range from -55°C to +150°C, with a typical gate charge of 7.5 nC.

Feature Summary

Dual P-channel configuration for efficient high-side switching applications
Low on-state resistance minimizes conduction losses
Compact leadless package design optimizes PCB space utilization

Applications

Power management circuits
Load switching applications
DC/DC converter output stages

Procurement Notes

Verify the specific suffix against official Nexperia documentation to confirm exact tape-and-reel specifications. Ensure the ordering part number matches the required packaging format. Confirm RoHS compliance status through the manufacturer's latest product compliance declarations before finalizing procurement orders.

Selection Notes

Select this component when a compact dual P-channel solution is required for low-voltage power paths. Evaluate thermal performance based on the specified power dissipation and package thermal resistance. Compare the on-resistance characteristics against system efficiency requirements to ensure adequate current handling capabilities.

Part Context

This component belongs to Nexperia's portfolio of small-signal MOSFETs designed for portable and industrial electronics. The DFN-2020-6 package provides a robust thermal path while maintaining a minimal footprint. It serves as a specialized alternative to discrete single-channel solutions in space-constrained designs.

Replacement Considerations

Consult official Nexperia substitution guides for verified equivalents. Cross-reference pinouts and electrical parameters carefully when considering alternatives from other manufacturers.
