RSX201LAM30TR is listed in the Single Diodes range at ChipApex. The manufacturer field lists Rohm Semiconductor. Its product description is DIODE SCHOTTKY 30V 2A TUMD2M. Review the specifications below when checking this part for your BOM.
Single Diodes specifications for RSX201LAM30TR
- Description：DIODE SCHOTTKY 30V 2A TUMD2M
- Series：-
- Mfr：Rohm Semiconductor
- Package：Tape & Reel (TR),Cut Tape (CT)
- Technology：Schottky
- Voltage - DC Reverse (Vr) (Max)：30 V
- Current - Average Rectified (Io)：2A
- Voltage - Forward (Vf) (Max) @ If：440 mV @ 2 A
- Speed：Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr)：-
- Current - Reverse Leakage @ Vr：150 µA @ 30 V
- Capacitance @ Vr, F：-
- Mounting Type：Surface Mount
- Package / Case：2-SMD, Flat Leads
- Supplier Device Package：TUMD2M
- Operating Temperature - Junction：150°C (Max)
- Grade：-
- Qualification：-
Single Diodes datasheet and documents for RSX201LAM30TR
Single Diodes Overview
The RSX201LAM30TR is a single Schottky barrier diode manufactured by ROHM Semiconductor, designed for surface mount applications in the SOD-128 package. It features a maximum repetitive reverse voltage of 30 V and an average rectified forward current rating of 2 A. The device exhibits a low forward voltage drop of 440 mV at 2 A and a maximum reverse leakage current of 150 uA at 30 V. It supports a forward surge current of 60 A and operates within a junction temperature range up to +150 °C.
Single Diodes Feature Summary
- Low forward voltage characteristics for improved efficiency
- Low reverse leakage current performance
- High reliability construction suitable for demanding environments
Single Diodes Applications
- General purpose rectification circuits
- Automotive electronic systems requiring AEC-Q101 compliance
- DC-DC converter output stages
Single Diodes Procurement Notes
Verify the specific suffix 'TR' indicates tape and reel packaging configuration. Confirm RoHS and REACH SVHC compliance status through official documentation before integration. Ensure the ordering part number matches the required automotive grade specifications for your design.
Single Diodes Selection Notes
Select this component when a 30 V reverse voltage rating and 2 A continuous current capacity are required in a compact SOD-128 footprint. Consider the low forward voltage for thermal management in high-efficiency designs. Verify that the 60 A surge current capability meets transient protection requirements.
Single Diodes Part Context
This part belongs to the RSX201 series of Schottky barrier diodes from ROHM Semiconductor. The series includes variants with different current ratings and packages, such as the RSX201VYM30FHTR in SOD-323HE. The LAM30 variant specifically targets higher current applications compared to lower-rated siblings in the same voltage class.
Single Diodes Replacement Considerations
The RSX201LAM30TF is a similar level replacement with identical pinout and package. Verify if the TF suffix denotes a specific packaging or quality tier difference before substitution.
