Product Detailed Parameters
- Description：DIODE ARRAY GP 1000V 8A TO263AB
- Series：-
- Mfr：Diotec Semiconductor
- Package：Tube
- Diode Configuration：1 Pair Series Connection
- Technology：Standard
- Voltage - DC Reverse (Vr) (Max)：1000 V
- Current - Average Rectified (Io) (per Diode)：8A
- Voltage - Forward (Vf) (Max) @ If：1.1 V @ 8 A
- Speed：Standard Recovery >500ns, > 200mA (Io)
- Reverse Recovery Time (trr)：1.5 µs
- Current - Reverse Leakage @ Vr：5 µA @ 1000 V
- Operating Temperature - Junction：-50°C ~ 150°C
- Mounting Type：Surface Mount
- Package / Case：TO-263-3, D2PAK (2 Leads + Tab), TO-263AB
- Supplier Device Package：TO-263AB (D2PAK)
- Grade：-
- Qualification：-
Download product information
Overview
The S16MSD2 is a standard recovery rectifier manufactured by Diotec Semiconductor, designed for surface-mount applications. It features a D2PAK (DO-214AA) package configuration and supports a maximum repetitive reverse voltage of 1000 V with an average forward current rating of 16 A. The device exhibits a maximum forward voltage of 1.1 V and a reverse leakage current of 5 µA. Key electrical characteristics include a peak non-repetitive surge current capacity of 300 A and a typical reverse recovery time of 1.5 µs. Operating temperature ranges span from -55 °C to +175 °C.
Feature Summary
- High current handling capability suitable for power supply output stages
- Robust surge current tolerance for transient protection
- Fast standard recovery speed for efficient switching operations
Applications
- DC-DC converter output rectification
- Power supply freewheeling diodes
- Industrial motor drive circuits
Procurement Notes
Verify the specific datasheet version and RoHS compliance status prior to integration. Confirm that the D2PAK footprint matches the target PCB design constraints. Ensure thermal management solutions account for the 16 A continuous current rating and junction temperature limits under expected load conditions.
Selection Notes
Select this component when high current density and compact surface-mount packaging are required. The 1000 V rating provides adequate margin for industrial DC bus applications. Consider the 1.5 µs recovery time for compatibility with switching frequencies in standard power conversion topologies.
Part Context
This part belongs to Diotec's discrete semiconductor rectifier portfolio, specifically targeting high-power surface-mount requirements. It complements the manufacturer's range of through-hole and smaller SMD diodes, offering a balance between current capacity and board space efficiency for modern electronic equipment.
Replacement Considerations
Publicly confirmed substitute part numbers are not available in the provided documentation. Cross-reference with other manufacturers' 16 A, 1000 V D2PAK rectifiers only after verifying pinout compatibility and electrical parameter equivalence.
