SBLF1040CT-E3/45

Description：DIODE ARR SCHOTT 40V 5A ITO220AB
Series：-

SKU:c9b3c108aa46 Category: Diode Arrays Brand: Vishay General Semiconductor - Diodes Division

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

SBLF1040CT-E3/45 is listed in the Diode Arrays range at ChipApex. The manufacturer field lists Vishay General Semiconductor - Diodes Division. Its product description is DIODE ARR SCHOTT 40V 5A ITO220AB. Review the specifications below when checking this part for your BOM.

Diode Arrays specifications for SBLF1040CT-E3/45

Description：DIODE ARR SCHOTT 40V 5A ITO220AB
Series：-
Mfr：Vishay General Semiconductor - Diodes Division
Package：Tube
Diode Configuration：1 Pair Common Cathode
Technology：Schottky
Voltage - DC Reverse (Vr) (Max)：40 V
Current - Average Rectified (Io) (per Diode)：5A
Voltage - Forward (Vf) (Max) @ If：550 mV @ 5 A
Speed：Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr)：-
Current - Reverse Leakage @ Vr：500 µA @ 40 V
Operating Temperature - Junction：-40°C ~ 125°C
Mounting Type：Through Hole
Package / Case：TO-220-3 Full Pack, Isolated Tab
Supplier Device Package：ITO-220AB
Grade：-
Qualification：-

Diode Arrays datasheet and documents for SBLF1040CT-E3/45

SBLF1040CT-E3/45

Diode Arrays Overview

The SBLF1040CT-E3/45 is a Schottky rectifier manufactured by Vishay General Semiconductor - Diodes Division. It features a dual common cathode configuration housed in a TO-220-2 FP through-hole package with two pins. The device supports a maximum continuous forward current of 10 A and a repetitive peak reverse voltage of 40 V. Key electrical parameters include a maximum forward voltage of 0.6 V, a surge current rating of 250 A, and a reverse leakage current of 1000 µA. It operates within a junction temperature range of -40°C to +125°C.

Diode Arrays Feature Summary

Utilizes silicon Schottky technology for low forward voltage drop and high efficiency.
Features a dual common cathode configuration suitable for bridge or full-wave rectification.
Designed for through-hole mounting in a robust TO-220-2 FP package.

Diode Arrays Applications

DC-to-DC converters
Free-wheeling diodes in power supplies
Polarity protection circuits

Diode Arrays Procurement Notes

Verify the specific suffix against official Vishay documentation to confirm pinout and thermal characteristics. Ensure the procurement channel provides valid RoHS compliance certificates. Cross-reference the manufacturer part number with authorized distributor databases to confirm authenticity and traceability before finalizing orders.

Diode Arrays Selection Notes

Select this component when a dual common cathode Schottky rectifier is required for low-voltage, high-current applications. The TO-220-2 FP package offers efficient heat dissipation compared to smaller surface-mount options. Consider the 40V rating and 10A current capacity relative to the circuit's peak reverse voltage and average forward current requirements.

Diode Arrays Part Context

This component belongs to the SBLF series of Schottky rectifiers from Vishay. The series is characterized by its use of silicon Schottky barrier technology, which provides superior switching performance and lower power loss compared to standard PN junction rectifiers. The E3 suffix indicates compliance with RoHS directives.
