SL 2 025 22 S

Headers, Male Pins Overview

The SL 2 025 22 S is a surface-mount board connector manufactured by Fischer Elektronik. It features a male contact configuration with 22 positions arranged in two rows. The connector utilizes a 2.54 mm (0.100 inch) pitch and operates within a temperature range of -40°C to +163°C. Contact plating consists of gold over nickel for the mating interface, while the termination side is tin-plated. The housing is constructed from glass-fiber reinforced polyamide (PA46/nylon 4/6).

Headers, Male Pins Feature Summary

• Surface-mount design for automated PCB assembly processes.
• Dual-row male header configuration providing high-density interconnect capability.
• Gold-plated mating contacts ensure reliable signal transmission and corrosion resistance.
• Thermoplastic insulation material rated for extended operational temperatures.

Headers, Male Pins Applications

• Industrial control system circuit boards.
• Consumer electronics internal connectivity.
• Communication equipment signal routing.
• Automotive electronic module interfaces.

Headers, Male Pins Procurement Notes

Verify the specific suffix 'S' against the manufacturer's current datasheet to confirm surface-mount terminal specifications. Ensure compatibility with standard reflow soldering profiles compatible with tin-plated terminations. Confirm that the 2.54 mm pitch aligns with the target PCB footprint design requirements before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a low-profile, dual-row male connector is required for surface-mount applications. The 2.54 mm pitch offers standard spacing compatibility with common ribbon cables or mating headers. Consider the thermal rating of +163°C if the application involves high-temperature environments or specific soldering processes requiring elevated thermal tolerance.

Headers, Male Pins Part Context

This part belongs to the Fischer Elektronik SL series of precision board connectors. The series provides various configurations including through-hole and surface-mount options with different pin counts. The SL 2 025 variant specifically denotes a compact form factor designed for space-constrained electronic assemblies requiring robust mechanical stability and electrical performance.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 2.54 mm pitch, 2x11 row configuration, and surface-mount termination style. Verify that alternative components offer equivalent gold-over-nickel contact plating and similar PA46 insulation materials to maintain environmental reliability standards across the operating temperature range.
