TAS5701PAP-P

Overview

The TAS5701PAPR is a stereo digital audio power amplifier manufactured by Texas Instruments, housed in a 64-pin HTQFP package. It delivers 20 watts of output power and supports I2S digital input interfaces. The device operates within a temperature range of 0 to 85 degrees Celsius and features hardware-controlled functionality for system integration.

Feature Summary

• Stereo digital audio amplification with integrated Class-D topology
• Hardware-controlled operation mode for simplified system management
• Direct I2S digital interface compatibility for high-fidelity signal processing

Applications

• Consumer electronics requiring stereo digital audio output
• Home audio systems utilizing I2S source components
• Portable devices needing efficient digital amplification

Procurement Notes

Verify the exact suffix against official documentation, as 'PAP' typically denotes the HTQFP-64 package variant. Confirm RoHS compliance and lead times directly with Texas Instruments or authorized distributors. Ensure the specific revision matches your design requirements before finalizing procurement orders.

Selection Notes

Select this component when a stereo Class-D amplifier with direct I2S connectivity is required. It is suitable for applications demanding hardware control rather than software-based configuration. Verify that the 64-pin HTQFP footprint fits your PCB layout constraints and thermal management strategy.

Part Context

This part belongs to the TAS570x series of digital audio power amplifiers from Texas Instruments. These devices are designed for consumer audio applications, offering high efficiency and sound quality through digital inputs. The series includes various pin counts and power configurations to suit different form factors.

Replacement Considerations

Check for TAS5701 variants with different packaging suffixes if the HTQFP-64 is unavailable. Consider the TAS5706A or TAS5709A for alternative channel configurations or package types within the same manufacturer's portfolio.
