VS-SD1500C04L

Description：DIODE STD 400V 1600A DO200AB
Series：-
Mfr：Vishay General Semiconductor - Diodes Division
Package：Bulk

SKU:6787770d7b05 Category: Single Diodes Brand: Vishay General Semiconductor - Diodes Division

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

VS-SD1500C04L is listed in the Single Diodes range at ChipApex. The manufacturer field lists Vishay General Semiconductor - Diodes Division. Its product description is DIODE STD 400V 1600A DO200AB. Review the specifications below when checking this part for your BOM.

Single Diodes specifications for VS-SD1500C04L

Description：DIODE STD 400V 1600A DO200AB
Series：-
Mfr：Vishay General Semiconductor - Diodes Division
Package：Bulk
Technology：Standard
Voltage - DC Reverse (Vr) (Max)：400 V
Current - Average Rectified (Io)：1600A
Voltage - Forward (Vf) (Max) @ If：1.64 V @ 3000 A
Speed：Standard Recovery >500ns, > 200mA (Io)
Reverse Recovery Time (trr)：-
Current - Reverse Leakage @ Vr：50 mA @ 400 V
Capacitance @ Vr, F：-
Mounting Type：Clamp On
Package / Case：DO-200AB, B-PUK
Supplier Device Package：DO-200AB, B-PUK
Operating Temperature - Junction：-
Grade：-
Qualification：-

Single Diodes datasheet and documents for VS-SD1500C04L

VS-SD1500C04L

Single Diodes Overview

The VS-SD1500C04L is a standard recovery diode from the Vishay SD1500C..L series, utilizing the B-PUK (DO-200AB) case style. It features a maximum repetitive peak reverse voltage of 400 V and a non-repetitive peak reverse voltage of 500 V. The device supports a maximum average forward current of 1600 A at a heatsink temperature of 55 °C and an RMS forward current of 3010 A. Surge capabilities include a peak non-repetitive surge current of 16,600 A at 50 Hz. Operating junction temperatures range from -40 to +180 °C.

Single Diodes Feature Summary

High surge current capability with significant I2t fusing ratings for robust protection
Diffused junction construction within the Hockey PUK version for high reliability
Low thermal resistance enabling efficient heat dissipation in double-side cooled configurations

Single Diodes Applications

Converters
Power supplies
Machine tool controls
High power drives
Medium traction applications

Single Diodes Procurement Notes

Verify the specific voltage code suffix against the required circuit parameters before ordering. Confirm that the mounting force requirements align with the mechanical specifications provided in the datasheet. Ensure the cooling method matches the thermal resistance values used in your design calculations. Check for any regional technical support contacts if further validation is needed.

Single Diodes Selection Notes

Select this component when high current handling and robust surge tolerance are required in industrial environments. Consider the single-side versus double-side cooling options based on available thermal management infrastructure. Evaluate the conduction angle characteristics to ensure the average forward current rating remains within safe operating limits under actual load conditions.

Single Diodes Part Context

This part belongs to the VS-SD1500C..L series of standard recovery diodes manufactured by Vishay Semiconductors. The series covers a wide voltage range from 400 V to 3000 V, all sharing the same high-current physical package. The '04' designation specifically indicates the 400 V voltage rating variant within this family.
