2PA1576Q,115

Single Bipolar Transistors Overview

The 2PA1576Q,115 is a dual PNP bipolar junction transistor (BJT) from Nexperia, housed in an SOT-363 surface-mount package. It features a collector-emitter voltage of -50 V and a continuous collector current of -100 mA per transistor. The device operates within a temperature range of -55 °C to +150 °C and is qualified to AEC-Q101 standards for automotive applications.

Single Bipolar Transistors Feature Summary

• Dual PNP configuration in a compact SOT-363 package
• Qualified to AEC-Q101 automotive reliability standards
• High thermal stability with a maximum junction temperature of 150 °C

Single Bipolar Transistors Applications

• Automotive electronic control units
• General-purpose switching circuits
• Signal conditioning modules

Single Bipolar Transistors Procurement Notes

Verify the specific suffix '115' against official Nexperia documentation to confirm tape-and-reel packaging specifications. Ensure the component meets AEC-Q101 requirements for your target application environment. Cross-reference the datasheet revision date to validate electrical characteristics before finalizing procurement orders.

Single Bipolar Transistors Selection Notes

Select this component when a dual PNP configuration is required in a minimal footprint. The SOT-363 package suits space-constrained designs. Verify that the -50 V rating and -100 mA current limits align with circuit demands. Confirm compatibility with automated assembly processes due to the surface-mount format.

Single Bipolar Transistors Part Context

This part belongs to Nexperia's portfolio of small-signal transistors designed for high-volume manufacturing. The 2PA series offers matched pairs for balanced performance in differential or push-pull configurations. It complements other discrete semiconductor solutions for logic and analog signal processing tasks.

Single Bipolar Transistors Replacement Considerations

Consult official Nexperia substitution guides for verified equivalents. Generic replacements may not match AEC-Q101 qualification or pinout compatibility. Validate thermal resistance and hFE matching characteristics before substituting.
