2SA1965-S-TL-E

Single Bipolar Transistors Overview

The 2SA1965-S-TL-E is a PNP epitaxial planar silicon transistor manufactured by Sanyo. It features an ultrasmall SSFP package designed for compact applications. The device supports a collector current of 0.1A and offers a collector-emitter breakdown voltage of 10V. This single-element component is engineered for muting circuit applications, enabling equipment to remain small and slim while maintaining reliable performance in signal processing tasks.

Single Bipolar Transistors Feature Summary

• Ultrasmall-sized package design facilitating compact and slim equipment construction
• PNP epitaxial planar silicon structure optimized for muting circuit applications

Single Bipolar Transistors Applications

• Muting circuits
• Compact audio equipment
• Signal processing modules

Single Bipolar Transistors Procurement Notes

Verify the manufacturer designation carefully, as distribution channels may list this component under AMI Semiconductor or onsemi due to corporate acquisitions. Confirm the specific suffix -S-TL-E matches the required packaging and tape-and-reel specifications. Ensure the datasheet aligns with the intended muting circuit requirements before finalizing procurement orders.

Single Bipolar Transistors Selection Notes

Select this component when space constraints are critical due to its ultrasmall SSFP package. It is suitable for low-current applications requiring a 0.1A rating and 10V breakdown voltage. Consider the PNP configuration for muting functions where compactness and slim profile integration are primary design drivers.

Single Bipolar Transistors Part Context

This part belongs to the Sanyo small-signal bipolar transistor family. It is often associated with similar models like the 2SA1979 series within the same product line. The component serves as a discrete solution for muting functions in consumer electronics, distinguishing itself through its specialized ultra-small form factor compared to standard transistors.

Single Bipolar Transistors Replacement Considerations

Public confirmed substitute part numbers are not explicitly documented in the provided source material. Verify compatibility with equivalent PNP transistors having matching 0.1A current and 10V voltage ratings if direct substitution is necessary.
