305-014-500-512

Edgeboard Connectors Overview

The EDAC Inc. 305-014-500-512 is a standard card edge connector header from the 305 series, designed for vertical panel mount applications. It features 14 positions arranged in a dual row configuration with a 3.96 mm pitch. The connector supports a maximum board thickness of 1.57 mm and utilizes gold-plated copper alloy contacts to ensure reliable signal transmission. Rated for 5 A current, it employs solder lug termination for secure wire connections. The housing is constructed from thermoplastic polyester, providing durability and insulation.

Edgeboard Connectors Feature Summary

• Dual-row header design accommodating two rows of contacts for increased density
• Vertical panel mount orientation for stable structural integration
• Gold-plated copper alloy contacts ensuring corrosion resistance and conductivity
• Solder lug termination method for robust wire hole connections

Edgeboard Connectors Applications

• Industrial control systems requiring durable interconnects
• Communication equipment backplanes
• Automotive electronic modules
• Medical device circuit boards

Edgeboard Connectors Procurement Notes

Verify that the specific part number matches the required 14-position count and dual-row configuration before procurement. Confirm that the solder lug termination type aligns with the wiring harness specifications. Ensure the operating temperature range of -40 C to +105 C meets the environmental requirements of the target application. Check RoHS compliance status if restricted substances are a concern for the project.

Edgeboard Connectors Selection Notes

Select this component when a vertical panel mount solution is required for card edge interfaces. The 3.96 mm pitch dictates the compatible PCB or card edge width. Verify that the 1.57 mm maximum board thickness accommodates the target electronics. Consider the 5 A current rating against the load requirements. Choose this model over single-row variants if higher pin density per unit height is necessary.

Edgeboard Connectors Part Context

This component belongs to the EDAC 305 series of standard card edge connectors. The series offers various position counts and termination styles while maintaining consistent mechanical dimensions and electrical ratings. The 305 series is widely used in industrial and commercial applications where reliable, high-current connections are essential. This specific variant provides a mid-range position count suitable for moderate I/O requirements.

Edgeboard Connectors Replacement Considerations

Direct substitutes within the same series include other 305-series headers with matching pitch and termination. Verify compatibility by comparing position counts and row configurations. Cross-reference with EDAC documentation for alternative part numbers offering similar electrical characteristics and mechanical footprints.
