801-83-023-30-002101

Headers, Receptacles, Female Sockets Overview

The Preci-Dip 801-83-023-30-002101 is a 23-position socket connector from the 801 series, designed for surface mount applications. It features a 0.100 inch (2.54mm) pitch and utilizes gold-plated contacts with a thickness of 29.5µin (0.75µm). The housing is constructed from black PCT material reinforced with glass fiber, rated UL94 V-0. Rated for 3A current and 150V DC, it operates within a temperature range of -55°C to 125°C. The connector employs a push-pull locking mechanism and uses tin-plated copper beryllium contacts.

Headers, Receptacles, Female Sockets Feature Summary

• Surface mount socket design with push-pull locking for secure board-to-board connections
• Gold-plated contact surfaces ensuring reliable signal transmission in demanding environments
• High-temperature resistant PCT insulation material with UL94 V-0 flammability rating

Headers, Receptacles, Female Sockets Applications

• Board-to-board interconnections in industrial control systems
• Signal routing in automotive electronic modules
• Connections in telecommunications equipment requiring robust surface mount solutions

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific suffix codes against official Preci-Dip documentation to confirm exact plating thickness and packaging variations. Ensure compatibility with mating header specifications regarding contact length and insulation height. Confirm RoHS compliance status through manufacturer certificates prior to final procurement decisions.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a surface mount socket configuration is required for high-density layouts. The 2.54mm pitch suits standard PCB designs, while the push-pull feature aids in assembly stability. Consider the operating temperature range and current rating to ensure suitability for the target application's electrical and thermal conditions.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the Preci-Dip 801 series, which offers various configurations including through-hole and surface mount options. The series is characterized by its modular design, allowing for different pin counts and locking mechanisms. The 801-83 variant specifically denotes the surface mount socket type within this family.

Headers, Receptacles, Female Sockets Replacement Considerations

Direct substitutes may include other Preci-Dip 801 series sockets with matching pin counts and mounting styles. Verify mechanical dimensions and electrical ratings before substituting with components from other manufacturers to ensure interface compatibility.
