830-80-014-40-001101

Headers, Male Pins Overview

Preci-Dip part number 830-80-014-40-001101 is a single-row male pin header from the 830 series. It features 14 positions with a 2.00mm (0.079 inch) pitch. The connector utilizes surface mount right-angle termination for PCB integration. Rated at 3A current and 150V DC, it employs brass contacts with tin plating. The housing consists of black glass-fiber reinforced liquid crystal polymer (LCP), meeting UL94 V-0 flammability standards. Operating temperature ranges from -55°C to 125°C.

Headers, Male Pins Feature Summary

• Surface mount right-angle design facilitates compact board-to-board connections.
• Tin-plated brass contacts ensure reliable conductivity and corrosion resistance.
• High-temperature LCP insulation supports operation in demanding thermal environments.

Headers, Male Pins Applications

• Board-to-board interconnects
• Surface mount electronic assemblies
• Compact consumer electronics

Headers, Male Pins Procurement Notes

Verify the specific suffix codes against manufacturer documentation to confirm exact termination style and contact material specifications. Ensure compatibility with automated pick-and-place equipment due to the surface mount right-angle configuration. Cross-reference the 830 series datasheet for precise mechanical dimensions and soldering profile requirements before finalizing procurement.

Headers, Male Pins Selection Notes

Select this component when a low-profile, right-angle surface mount header is required for high-density layouts. The 2.00mm pitch offers a balance between signal density and spacing reliability. Consider the 3A rating and 150V limit for circuit safety margins. Verify that the right-angle orientation aligns with the mechanical constraints of the target enclosure and adjacent components.

Headers, Male Pins Part Context

This component belongs to the Preci-Dip 830 series, which specializes in board-to-board connectors. The series provides various row counts and pitch options, including 1.00mm, 1.27mm, and 2.00mm configurations. The 830 series is designed for applications requiring robust performance in space-constrained environments, offering both through-hole and surface mount variants with consistent electrical characteristics across the lineup.

Headers, Male Pins Replacement Considerations

Compatible mating sockets are found within the same 830 series family, such as female headers with matching 2.00mm pitch. Ensure replacement parts maintain identical mounting type and contact plating to preserve electrical continuity and mechanical fit.
